CSD18534Q5A Texas Instruments CSD18534Q5A Real Image CSD18534Q5A real image3116 CSD18534Q5A Real Image1 CSD18534Q5A Real Image2 CSD18534Q5A Real Image3
Same model may have multiple batches, images only for reference.
CSD18534Q5A Texas Instruments CSD18534Q5A Real Image CSD18534Q5A real image3116 CSD18534Q5A Real Image1 CSD18534Q5A Real Image2 CSD18534Q5A Real Image3
CSD18534Q5A Texas Instruments CSD18534Q5A Real Image CSD18534Q5A real image3116 CSD18534Q5A Real Image1 CSD18534Q5A Real Image2 CSD18534Q5A Real Image3
Same model may have multiple batches, images only for reference.

CSD18534Q5A

Part No CSD18534Q5A
Manufacturer Texas Instruments
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CH 60V 8SON
Datasheet
CSD18534Q5A Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 60V
Continuous Drain Current at 25°C 13A (Ta), 50A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 4.5V, 10V
Gate-Source Threshold Voltage 2.3V @ 250μA
Max Gate Charge 22nC @ 10V
Max Input Capacitance 1770pF @ 30V
Maximum Gate-Source Voltage ±20V
Power Dissipation (Max) 3.1W (Ta), 77W (Tc)
Maximum Rds On at Id,Vgs 9.8 mOhm @ 14A, 10V
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package 8-VSONP (5x6)
Dimension 8-PowerTDFN
Win Source Part Number 013375-CSD18534Q5A
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian CSD18534Q5A CAD Model

Description

Product Description

The CSD18534Q5A offers a superior N-channel MOSFET design, focusing on high efficiency and thermal management. This model provides a balance between performance and cost, suitable for various applications.

Applications

  • Telecommunication Power Systems
  • AC-DC Power Supplies
  • Industrial Power Supplies
  • General Switching Applications

Features and Benefits

  • Optimized On-State Resistance: Enhances energy efficiency.
  • Thermal Stability: Prolongs device lifespan in demanding environments.
  • Fast Switching Characteristics: Supports rapid operation cycles.

Additional Details

Supported by extensive documentation and design tools, the CSD18534Q5A integrates seamlessly into new projects.
