DRV8702QRHBRQ1 Automotive H-Bridge Driver from Texas Instruments

The DRV8702QRHBRQ1 is a state-of-the-art automotive H-Bridge driver designed and manufactured by Texas Instruments, a leader in semiconductor solutions. This robust integrated circuit is engineered to provide efficient and reliable control for DC motors and other inductive loads in automotive applications.

Encased in a compact 32-pin VQFN package, the DRV8702QRHBRQ1 offers a wide operating voltage range from 4.5V to 45V, making it highly versatile for various automotive voltage systems. With an output current capability of up to 3.5A continuous and 5.2A peak, this driver can handle a broad spectrum of motor driving requirements.

One of the key features of the DRV8702QRHBRQ1 is its integrated charge pump which ensures robust operation, even at low supply voltages. This ensures that the gates of the H-bridge MOSFETs are driven effectively, providing consistent motor performance. Additionally, the device is equipped with a range of protective features including under-voltage lockout, over-current protection, and thermal shutdown, which safeguard the system against various fault conditions.

Flexibility is at the core of the DRV8702QRHBRQ1's design. It supports both PWM and PH/EN control interfaces, allowing designers to choose the most suitable control method for their application. Moreover, the device's integrated current-sense amplifier and two-stage charge pump design minimize the need for external components, which simplifies the design and reduces the overall solution size.

The DRV8702QRHBRQ1 is AEC-Q100 qualified, ensuring that it meets the stringent requirements of the automotive industry regarding temperature and reliability standards. It operates over a wide temperature range from -40°C to 125°C, which is essential for automotive environments that experience extreme temperature variations.

In summary, the DRV8702QRHBRQ1 from Texas Instruments is an excellent choice for automotive designers looking for a reliable, flexible, and high-performance H-Bridge driver. Its robust design, combined with advanced protective features and control interface options, makes it an ideal solution for a wide range of automotive motor control applications.
