ISO7242CDWR Real Image ISO7242CDWR real image ISO7242CDWR real image579 ISO7242CDWR Real Image
Same model may have multiple batches, images only for reference.
ISO7242CDWR Real Image ISO7242CDWR real image ISO7242CDWR real image579 ISO7242CDWR Real Image
ISO7242CDWR Real Image ISO7242CDWR real image ISO7242CDWR real image579 ISO7242CDWR Real Image
Same model may have multiple batches, images only for reference.

ISO7242CDWR

Part No ISO7242CDWR
Manufacturer Texas Instruments
Catalog Digital Isolators
Description DGTL ISO 2.5KV GEN PURP 16SOIC
Datasheet
ISO7242CDWR Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Technology Capacitive Coupling
Type General Purpose
Isolated Power No
Number of Channels 4
Inputs - Side 1/Side 2 2/2
Channel Type Unidirectional
Isolation Voltage 2500Vrms
Common Mode Transient Immunity (Min) 25kV/μs
Data Rate 25Mbps
Propagation Delay tpLH / tpHL (Max) 42ns, 42ns
Pulse Width Distortion (Max) 2.5ns
Rise and Fall Time 2ns, 2ns
Supply Voltage - Operating 3.15 V to 5.5 V
Temperature Range - Operating -40°C to 125°C
Case / Package 16-SOIC
Win Source Part Number 002071-ISO7242CDWR
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name ISO7242CDWR
Introduction Date October 01, 2007
ECCN EAR99
Country of Origin Taiwan
Halogen Free Compliant
Estimated EOL Date 2028
Ultra Librarian 3D Model Ultra Librarian ISO7242CDWR CAD Model

Description

The ISO7242CDWR is a high-performance, quad-channel digital isolator product developed by Texas Instruments, a leading global semiconductor company.

  • Supply Voltage Range: 3.0 to 5.5 volts
  • Data Rate: 25 Mbps
  • Power Consumption: Low
  • Isolation Voltage: 2500 Vrms
  • Operating Temperature Range: -40°C to +125°C
  • ESD Withstand: Up to 4 kV
  • Fail-Safe Outputs: Yes
  • Package: 16-SOIC
