LM1086CSX-ADJ/NOPB Real Image LM1086CSX-ADJ/NOPB Real Image
Same model may have multiple batches, images only for reference.
LM1086CSX-ADJ/NOPB Real Image LM1086CSX-ADJ/NOPB Real Image
LM1086CSX-ADJ/NOPB Real Image LM1086CSX-ADJ/NOPB Real Image
Same model may have multiple batches, images only for reference.

LM1086CSX-ADJ/NOPB

Part No LM1086CSX-ADJ/NOPB
Manufacturer Texas Instruments
Catalog PMIC - Voltage Regulators - Linear
Description IC REG LDO ADJ 1.5A DDPAK
Datasheet
LM1086CSX-ADJ/NOPB Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Output Type Adjustable
Number of Regulators 1
Maximum Input Voltage 29V
Nominal Output Voltage (Min/Fixed) 1.2V
Maximum Output Voltage 15V
Dropout Voltage-Max 1.5V @ 1.5A
Output Current 1.5A
Operating Supply Current 5mA to 10mA
PSRR 75dB (120Hz)
Control Protection Features Over Current, Over Temperature, Short Circuit
Temperature Range - Operating 0°C to 125°C
Regulator Topology Positive Adjustable
Output Voltage 1.2 V to 15 V
Voltage - Dropout (Typical) 1.3V @ 1.5A
Mounting SMD (SMT)
Case / Package DDPAK/TO-263-3
Win Source Part Number 018639-LM1086CSX-ADJ/NOPB
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian LM1086CSX-ADJ/NOPB CAD Model

Description

The LM1086CSX-ADJ/NOPB is a high-quality, high-performance voltage regulator designed and manufactured by Texas Instruments, a global leader in semiconductor solutions.

  • Output Voltage Range: 1.25V to 15V
  • Maximum Output Current: 1.5A
  • Dropout Voltage: 1.5V @ maximum output
  • Operating Temperature Range: -40°C to 125°C
  • Safety features: Current limiting and thermal shutdown
