LM1117DT-ADJ Real Image LM1117DT-ADJ Real Image
Same model may have multiple batches, images only for reference.
LM1117DT-ADJ Real Image LM1117DT-ADJ Real Image
LM1117DT-ADJ Real Image LM1117DT-ADJ Real Image
Same model may have multiple batches, images only for reference.

LM1117DT-ADJ

Part No LM1117DT-ADJ
Manufacturer Texas Instruments
Catalog PMIC - Voltage Regulators - Linear
Description IC REG LDO ADJ 0.8A TO252-3
Datasheet
LM1117DT-ADJ Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Tube/Rail
Status Active
Output Type Adjustable
Number of Regulators 1
Maximum Input Voltage 15V
Nominal Output Voltage (Min/Fixed) 1.25V
Maximum Output Voltage 13.8V
Dropout Voltage-Max 1.2V @ 800mA
Output Current 800mA
Operating Supply Current 5mA to 10mA
PSRR 75dB (120Hz)
Control Protection Features Over Current, Over Temperature
Temperature Range - Operating 0°C to 125°C
Regulator Topology Positive Adjustable
Output Voltage 1.25 V to 13.8 V
Voltage - Dropout (Typical) 1.2V @ 800mA
Mounting SMD (SMT)
Case / Package TO-252-3
Win Source Part Number 082580-LM1117DT-ADJ
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian LM1117DT-ADJ CAD Model

Description

The LM1117DT-ADJ from Texas Instruments is a highly efficient and reliable adjustable voltage regulator designed to offer a wide range of applications.

  • Output Voltage: adjustable output voltage from 1.25V to 13.8V
  • Output Current: 1A output current
  • Features: built-in thermal shutdown and current limit functions
  • Feature: output capacitor which improves transient response
  • Package: TO-252 package
  • Mounting: surface mount applications
  • Operating Temperature: wide temperature range from -40 to 125 degrees Celsius
