LM1117IDT-3.3 Texas Instruments LM1117IDT-3.3 real image942 LM1117IDT-3.3 Real Image1 LM1117IDT-3.3 Real Image2 LM1117IDT-3.3 Real Image3 LM1117IDT-3.3 label picture
Same model may have multiple batches, images only for reference.
LM1117IDT-3.3 Texas Instruments LM1117IDT-3.3 real image942 LM1117IDT-3.3 Real Image1 LM1117IDT-3.3 Real Image2 LM1117IDT-3.3 Real Image3 LM1117IDT-3.3 label picture
LM1117IDT-3.3 Texas Instruments LM1117IDT-3.3 real image942 LM1117IDT-3.3 Real Image1 LM1117IDT-3.3 Real Image2 LM1117IDT-3.3 Real Image3 LM1117IDT-3.3 label picture
Same model may have multiple batches, images only for reference.

LM1117IDT-3.3

Part No LM1117IDT-3.3
Manufacturer Texas Instruments
Catalog PMIC - Voltage Regulators - Linear
Description IC REG LDO 3.3V 0.8A TO252-3
Datasheet
LM1117IDT-3.3 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Tube/Rail
Status Active
Output Type Fixed
Number of Regulators 1
Maximum Input Voltage 15V
Nominal Output Voltage (Min/Fixed) 3.3V
Dropout Voltage-Max 1.2V @ 800mA
Output Current 800mA
Operating Supply Current 5mA to 10mA
PSRR 75dB (120Hz)
Control Protection Features Over Current, Over Temperature
Temperature Range - Operating -40°C to 125°C
Regulator Topology Positive Fixed
Output Voltage 3.3V
Voltage - Dropout (Typical) 1.2V @ 800mA
Mounting SMD (SMT)
Case / Package TO-252-3
Win Source Part Number 206284-LM1117IDT-3.3
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian LM1117IDT-3.3 CAD Model

Description

The LM1117IDT-3.3 is a high-performance voltage regulator manufactured by Texas Instruments, a leading global semiconductor company.

  • Output Current: 800mA
  • Output Voltage: 3.3V (fixed)
  • Input Voltage Range: 4.75V to 10V
  • Dropout Voltage: Low dropout voltage
  • Features: Built-in current limiting and thermal shutdown
  • Package: TO-252
  • RoHS compliant: Yes
