LM1117IMP-5.0/NOPB Texas Instruments LM1117IMP-5.0/NOPB Real Image LM1117IMP-5.0/NOPB real image945 LM1117IMP-5.0/NOPB real image946 LM1117IMP-5.0/NOPB real image947 LM1117IMP-5.0/NOPB Real Image1 LM1117IMP-5.0/NOPB Real Image2 LM1117IMP-5.0/NOPB Real Image3 LM1117IMP-5.0/NOPB Real Image4
LM1117IMP-5.0/NOPB Texas Instruments LM1117IMP-5.0/NOPB Real Image LM1117IMP-5.0/NOPB real image945 LM1117IMP-5.0/NOPB real image946 LM1117IMP-5.0/NOPB real image947 LM1117IMP-5.0/NOPB Real Image1 LM1117IMP-5.0/NOPB Real Image2 LM1117IMP-5.0/NOPB Real Image3 LM1117IMP-5.0/NOPB Real Image4
Same model may have multiple batches, images only for reference.

LM1117IMP-5.0/NOPB

Part No LM1117IMP-5.0/NOPB
Manufacturer Texas Instruments
Catalog PMIC - Voltage Regulators - Linear
Description IC REG LDO 5V 0.8A SOT223
Datasheet
LM1117IMP-5.0/NOPB Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Output Type Fixed
Number of Regulators 1
Maximum Input Voltage 15V
Nominal Output Voltage (Min/Fixed) 5V
Dropout Voltage-Max 1.2V @ 800mA
Output Current 800mA
Operating Supply Current 5mA to 10mA
PSRR 75dB (120Hz)
Control Protection Features Over Current, Over Temperature
Temperature Range - Operating -40°C to 125°C
Regulator Topology Positive Fixed
Output Voltage 5V
Voltage - Dropout (Typical) 1.2V @ 800mA
Mounting SMD (SMT)
Case / Package SOT-223
Win Source Part Number 018644-LM1117IMP-5.0/NOPB
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Application Field Used in Power Management
Ultra Librarian 3D Model Ultra Librarian LM1117IMP-5.0/NOPB CAD Model

Description

Product LM1117IMP-5.0/NOPB is an exceptional LDO (Low-Dropout) regulator designed by Texas Instruments, a renowned global semiconductor company.

  • Output Voltage: 5.0V
  • Maximum Input Voltage: 15V
  • Output Current: Up to 800mA
  • Dropout Voltage: Low
  • Self-Consumption Current: Very Low
  • Protection: Overcurrent and thermal protection
  • Package: SOT-223
  • Compliance: RoHS compliant and lead-free
  • Line and Load Regulation: Excellent
  • Output Voltage Accuracy: Commendable
  • Junction Temperature Range: -40 to 125 degrees Celsius
