LM2596S-5.0

Name: LM2596S-5.0
Brand: Texas Instruments
SKU: 181979
Availability: InStock
Rating: 4.93 (48 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	LM2596S-5.0
Manufacturer	Texas Instruments
Catalog	PMIC - Voltage Regulators - DC DC Switching Regulators
Description	Conv DC-DC 4.5V to 40V Inv/Step Down Single-Out 5V 3A 6-Pin(5+Tab) DDPAK Tube / IC REG BUCK 5V 3A TO263-5
Datasheet	LM2596S-5.0 Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Integrated Circuits
Manufacturer	Texas Instruments
Packaging	Tube/Rail
Status	Active
Purpose	Step-Down
Topology	Buck
Output Type	Fixed
Number of Outputs	1
Minimum Input Voltage	4.5V
Maximum Input Voltage	40V
Nominal Output Voltage (Min/Fixed)	5V
Output Current	3A
Frequency - Switching	150kHz
Synchronous Rectifier	No
Temperature Range - Operating	-40°C to 125°C (TJ)
Mounting	SMD (SMT)
Case / Package	DDPAK/TO-263-5
Win Source Part Number	082633-LM2596S-5.0
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Balance
Application Field	Used in Power Management, Consumer Electronics, Signal Processing
Family Name	LM2596
Introduction Date	December 01, 1997
Country of Origin	Malaysia
Halogen Free	Compliant
Estimated EOL Date	2031
Package	Tube
Product Status	Obsolete
Function	Step-Down
Output Configuration	Positive
Voltage - Input (Min)	4.5V
Voltage - Input (Max)	40V
Voltage - Output (Min/Fixed)	5V
Current - Output	3A
Operating Temperature	-40°C ~ 125°C (TJ)
Grade	-
Mounting Type	Surface Mount
Package / Case	TO-263-6, D²Pak (5 Leads + Tab), TO-263BA
Supplier Device Package	TO-263 (DDPAK-5)
Ultra Librarian 3D Model	Ultra Librarian LM2596S-5.0 CAD Model

Alternative Products

Description

The LM2596S-5.0 from Texas Instruments is a high-performance, monolithic power management solution that offers superior efficiency and flexibility.

Output Voltage: 5.0V
Load: 3A
Switching Frequency: 150kHz
Output Voltage Adjustment: 1.23V to 37V
Package: 5-pin TO-263
Junction Temperature Range: -40°C to +125°C
