LM2937IMPX-5.0 Texas Instruments LM2937IMPX-5.0 Real Image LM2937IMPX-5.0 real image1222 LM2937IMPX-5.0 real image1223 LM2937IMPX-5.0 Real Image1 LM2937IMPX-5.0 Real Image2
Same model may have multiple batches, images only for reference.
LM2937IMPX-5.0 Texas Instruments LM2937IMPX-5.0 Real Image LM2937IMPX-5.0 real image1222 LM2937IMPX-5.0 real image1223 LM2937IMPX-5.0 Real Image1 LM2937IMPX-5.0 Real Image2
LM2937IMPX-5.0 Texas Instruments LM2937IMPX-5.0 Real Image LM2937IMPX-5.0 real image1222 LM2937IMPX-5.0 real image1223 LM2937IMPX-5.0 Real Image1 LM2937IMPX-5.0 Real Image2
Same model may have multiple batches, images only for reference.

LM2937IMPX-5.0

Part No LM2937IMPX-5.0
Manufacturer Texas Instruments
Catalog PMIC - Voltage Regulators - Linear
Description IC REG LDO 5V 0.4A SOT223
Datasheet
LM2937IMPX-5.0 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Output Type Fixed
Number of Regulators 1
Maximum Input Voltage 26V
Nominal Output Voltage (Min/Fixed) 5V
Dropout Voltage-Max 1V @ 50mA
Output Current 400mA
Operating Supply Current 2mA to 20mA
Control Protection Features Over Temperature, Reverse Polarity, Short Circuit
Temperature Range - Operating -40°C to 85°C
Regulator Topology Positive Fixed
Output Voltage 5V
Voltage - Dropout (Typical) 1V @ 500mA
Mounting SMD (SMT)
Case / Package SOT-223-4
Win Source Part Number 090826-LM2937IMPX-5.0
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian LM2937IMPX-5.0 CAD Model

Description

The LM2937IMPX-5.0 is a high-quality, advanced technology product developed by the globally recognized company, Texas Instruments.

  • Type: Low dropout voltage regulator
  • Output Voltage: 5.0V
  • Maximum Current: 500mA
  • Dropout Voltage: Typically 0.6V @ full load
  • Protection Features: Internal short-circuit current limit and thermal shutdown protection mechanism
  • Output Transistor Safe-Area Compensation Feature: Yes
  • Package: Compact 8-pin NSOIC
