LM5118MHX

Part No LM5118MHX
Manufacturer Texas Instruments
Catalog PMIC - Voltage Regulators - DC DC Switching Controllers
Description IC REG CTRLR BCK/BCK-BST 20TSSOP
Datasheet
LM5118MHX Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Output Type Transistor Driver
Purpose Step-Down, Step-Up/Step-Down
Topology Buck, Buck-Boost
Number of Outputs 1
Output Phases 1
Supply Voltage - Operating 3 V to 75 V
Frequency - Switching 200kHz, 515kHz
Duty Cycle (Max) 80%
Synchronous Rectifier No
Clock Sync Yes
Control Features Enable, Frequency Control, Ramp, Soft Start
Temperature Range - Operating -40°C to 125°C (TJ)
Case / Package 20-HTSSOP
Win Source Part Number 088265-LM5118MHX
Family Name LM5118
Introduction Date April 30, 2008
ECCN EAR99
Estimated EOL Date Obsolete
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian LM5118MHX CAD Model

Description

The LM5118MHX from Texas Instruments is a versatile and highly efficient device designed to regulate voltage in a wide variety of applications.

  • Device Type: Buck-boost regulator controller
  • Input Voltage Range: 5.5V to 75V
  • Applications: Automotive, industrial, and telecommunications, battery-powered systems, power supply systems
  • Features: Seamlessly transition between step-down and step-up voltage modes, high-performance error amplifier
  • Integration: High-voltage startup regulator, current limit and thermal shutdown feature
  • Package: 20-pin TSSOP PowerPAD package
  • Compliance: RoHS compliant
