LM53601AQDSXRQ1

Part No LM53601AQDSXRQ1
Manufacturer Texas Instruments
Catalog PMIC - Voltage Regulators - DC DC Switching Regulators
Description IC REG BUCK ADJUSTABLE 1A 10WSON / Automotive Step Down DC-DC Converter
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Manufacturer Texas Instruments
Packaging Reel
Function Step-Down
Output Configuration Positive
Topology Buck
Output Type Adjustable
Number of Outputs 1
Voltage - Input (Min) 3.8V
Maximum Input Voltage 36V
Voltage - Output (Min/Fixed) 3.3V
Maximum Output Voltage 6V
Current - Output 1A
Frequency - Switching 2.1MHz
Synchronous Rectifier Yes
Temperature Range - Operating -40°C ~ 150°C
Mounting Style SMD
Manufacturer Package 10-WFDFN Exposed Pad
Supplier Device Package 10-WSON (3x3)
Manufacturer Pack Quantity 3,000
MSL Level 2 (1 Year)
Popularity Medium
Supply and Demand Status Balance
Win Source Part Number 805557-LM53601AQDSXRQ1
Ultra Librarian 3D Model Ultra Librarian LM53601AQDSXRQ1 CAD Model

Description

The LM53601AQDSXRQ1 is a high-performance, automotive-grade step-down voltage converter designed and manufactured by Texas Instruments (TI), a global leader in semiconductor technology. This advanced power management integrated circuit (IC) is specifically engineered to meet the rigorous demands of automotive applications, providing reliable and efficient voltage regulation for a wide range of electronic systems within vehicles.

Key Features

  • Input Voltage Range: The device supports a wide input voltage range from 3.5V to 36V, making it versatile for various automotive power supply scenarios, including those subject to cold-crank and stop-start conditions.
  • Output Voltage: It delivers an adjustable output voltage that can be set from 0.8V to 90% of Vin, with a maximum output current of 1A, catering to a broad spectrum of low-power applications.
  • High Efficiency: The LM53601AQDSXRQ1 boasts an excellent efficiency rate, reducing power loss and heat generation, which is critical for the longevity and reliability of automotive electronics.
  • Thermal Performance: With an enhanced thermal performance, the device operates reliably over a wide temperature range, which is essential for the diverse thermal environments encountered in automotive applications.
  • Robust Protection Features: It includes a suite of protection features such as overcurrent protection, thermal shutdown, and input undervoltage lockout, ensuring the safety and durability of the electronic systems it powers.
  • Small Package Size: The IC comes in a compact package, which is beneficial for space-constrained automotive environments.

Applications

The LM53601AQDSXRQ1 is ideal for a variety of automotive applications, including infotainment systems, advanced driver assistance systems (ADAS), body control modules, and other automotive-related power systems that require a stable and efficient supply of power.

Quality and Reliability

Texas Instruments is committed to delivering high-quality and reliable components. The LM53601AQDSXRQ1 is AEC-Q100 qualified, ensuring that it meets the stringent quality standards required for automotive industry components. With its robust design and proven performance, the LM53601AQDSXRQ1 is a trusted choice for automotive manufacturers seeking to enhance the performance and reliability of their vehicles' electronic systems.
