The Texas Instruments LMZ10505TZ-ADJ is a highly efficient, easy-to-use, 5A power module that combines a step-down DC/DC converter with power MOSFETs, a shielded inductor, and passives into a low-profile, QFN package. This power solution is suitable for a wide range of applications, including telecommunications, networking equipment, industrial, and consumer electronics.

Key Features

• Output Current: The LMZ10505TZ-ADJ is capable of delivering up to 5A of output current, making it suitable for powering heavy loads.
• Adjustable Output Voltage: This power module offers an adjustable output voltage range from 0.8V to 3.6V, allowing for versatility in different circuit designs.
• High Efficiency: With an efficiency of up to 95%, this module ensures minimal power loss and heat generation, which is crucial for maintaining system reliability.
• Integrated Shielding: The integrated inductor is shielded, which reduces electromagnetic interference (EMI), making it an excellent choice for noise-sensitive applications.
• Simple Design: The simplicity of the LMZ10505TZ-ADJ enables a quick and easy design process, as it requires only a few external components to operate.
• Thermal Performance: The module is designed with excellent thermal performance in mind, featuring a -40°C to 125°C operating junction temperature range.
• Protection Features: It includes built-in over-temperature and over-current protection, ensuring the safety and longevity of both the module and the application it powers.

Applications

• Telecommunications Equipment
• Networking Equipment such as Routers and Switches
• Industrial Systems
• Consumer Electronics
• Point-of-Load Conversions

Product Specifications

For detailed technical specifications, application notes, and support resources, please visit the Texas Instruments official website or contact your local TI distributor.
