LMZ14203TZ-ADJ

Part No LMZ14203TZ-ADJ
Manufacturer Texas Instruments
Catalog Power Supplies Board Mount DCDC Converters
Description Module DC-DC 1-OUT 0.8V to 6V 3A 18W 7-Pin TO-PMOD EP T/R / LMZ14203 3A SIMPLE SWITCHER® Power Module with 42V Maximum Input Voltage
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Manufacturer Texas Instruments
Win Source Part Number 1202555-LMZ14203TZ-ADJ
Manufacturer Homepage www.ti.com
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Application Field Used in Signal Processing, Consumer Electronics, Security, Communications & Networking, Imaging, Video & Vision, Defence, Military & Aerospace, Motor Drive & Control, Avionics
Family Name LMZ14203
Introduction Date January 15, 2010
Estimated EOL Date Obsolete / End of life
Ultra Librarian 3D Model Ultra Librarian LMZ14203TZ-ADJ CAD Model

Description

Product Overview: LMZ14203TZ-ADJ from Texas Instruments

The LMZ14203TZ-ADJ is a high-performance, easy-to-use power module from Texas Instruments, designed to meet a wide range of power requirements in various applications. This power module is a part of Texas Instruments' SIMPLE SWITCHER® series and is capable of delivering up to 3A of output current with exceptional power conversion efficiency and low output ripple.

Key Features

  • Adjustable Output Voltage: The LMZ14203TZ-ADJ allows users to set the output voltage from 0.8V to 6V using external resistors, providing flexibility for different voltage requirements.
  • Wide Input Voltage Range: It operates over an input voltage range of 6V to 42V, accommodating a variety of supply voltages.
  • High Efficiency: With an integrated shielded inductor, the module offers high efficiency and reduces the need for external components.
  • Thermal Performance: The innovative package design enhances thermal performance and simplifies heat management, even in demanding environments.
  • Protection Features: The module includes built-in features such as over-temperature protection, under-voltage lockout, and over-current protection, ensuring reliable operation and longevity.
  • Easy Integration: Its compact size and minimal external components requirement make it easy to integrate into a wide range of applications.

Applications

The LMZ14203TZ-ADJ is suitable for a variety of applications, including but not limited to:

  • Industrial and automation systems
  • Telecommunications equipment
  • Automotive infotainment and telematics
  • Consumer electronics
  • Point-of-load conversions

Quality and Reliability

Texas Instruments is known for its commitment to quality and reliability, and the LMZ14203TZ-ADJ is no exception. It is designed to meet the stringent requirements of industrial and automotive applications, ensuring a reliable power solution that stands the test of time.

Conclusion

With its adjustable output, wide input voltage range, high efficiency, and robust protection features, the LMZ14203TZ-ADJ from Texas Instruments is an excellent choice for designers looking for a compact, efficient, and reliable power module. Whether for industrial, automotive, or consumer applications, this power module simplifies the design process and accelerates time to market.
