LP2985AIM5-5.0 Real Image LP2985AIM5-5.0 real image1900 LP2985AIM5-5.0 Real Image
Same model may have multiple batches, images only for reference.
LP2985AIM5-5.0 Real Image LP2985AIM5-5.0 real image1900 LP2985AIM5-5.0 Real Image
LP2985AIM5-5.0 Real Image LP2985AIM5-5.0 real image1900 LP2985AIM5-5.0 Real Image
Same model may have multiple batches, images only for reference.

LP2985AIM5-5.0

Part No LP2985AIM5-5.0
Manufacturer Texas Instruments
Catalog PMIC - Voltage Regulators - Linear
Description IC REG LDO 5V 0.15A SOT23-5
Datasheet
LP2985AIM5-5.0 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Output Type Fixed
Number of Regulators 1
Maximum Input Voltage 16V
Nominal Output Voltage (Min/Fixed) 5V
Dropout Voltage-Max 0.58V @ 150mA
Output Current 150mA
Operating Supply Current 95μA to 2.5mA
PSRR 45dB (1kHz)
Control Features Enable
Protection Features Over Current, Over Temperature, Short Circuit
Temperature Range - Operating -40°C to 125°C
Regulator Topology Positive Fixed
Output Voltage 5V
Voltage - Dropout (Typical) 0.28V @ 150mA
Mounting SMD (SMT)
Case / Package SOT-23-5
Win Source Part Number 082942-LP2985AIM5-5.0
Family Name LP2985
Introduction Date March 01, 2000
ECCN EAR99
Country of Origin Malaysia
Halogen Free Compliant
Estimated EOL Date 2028
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Application Field Used in Consumer Electronics, Portable Devices, Computers & Computer Peripherals
Ultra Librarian 3D Model Ultra Librarian LP2985AIM5-5.0 CAD Model

Description

The LP2985AIM5-5.0 from Texas Instruments is a high-performance, low-noise, micro-power voltage regulator designed for a wide range of applications. It features a fixed output voltage of 5.0V and a maximum output current of 150mA.

  • Output Voltage: 5.0V
  • Maximum Output Current: 150mA
  • Dropout Voltage: 17mV @ light loads, 165mV @ 150mA
  • Features: Low noise operation, fast turn-on time
  • Safety Features: Thermal shutdown, current limit protection
  • Package: 5-pin SOT-23
  • Compliance: RoHS compliant, lead-free
