ISL80103IRAJZ-TK Real Image ISL80103IRAJZ-TK label picture ISL80103IRAJZ-TK label picture 2 ISL80103IRAJZ-TK real image10331 ISL80103IRAJZ-TK real image10332 ISL80103IRAJZ-TK Real Image1 ISL80103IRAJZ-TK Real Image2
Same model may have multiple batches, images only for reference.
ISL80103IRAJZ-TK Real Image ISL80103IRAJZ-TK label picture ISL80103IRAJZ-TK label picture 2 ISL80103IRAJZ-TK real image10331 ISL80103IRAJZ-TK real image10332 ISL80103IRAJZ-TK Real Image1 ISL80103IRAJZ-TK Real Image2
ISL80103IRAJZ-TK Real Image ISL80103IRAJZ-TK label picture ISL80103IRAJZ-TK label picture 2 ISL80103IRAJZ-TK real image10331 ISL80103IRAJZ-TK real image10332 ISL80103IRAJZ-TK Real Image1 ISL80103IRAJZ-TK Real Image2
Same model may have multiple batches, images only for reference.

ISL80103IRAJZ-TK

Part No ISL80103IRAJZ-TK
Manufacturer Intersil
Catalog PMIC - Voltage Regulators - Linear
Description IC REG LDO ADJ 3A 10DFN
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Intersil
Packaging Reel - TR
Status Active
Output Type Adjustable
Number of Regulators 1
Maximum Input Voltage 6V
Nominal Output Voltage (Min/Fixed) 0.8V
Maximum Output Voltage 5V
Dropout Voltage-Max 0.244V @ 3A
Output Current 3A
Operating Supply Current 9mA to 12mA
PSRR 62dB to 55dB (120Hz to 1kHz)
Control Features Enable, Power Good, Soft Start
Protection Features Over Temperature, Short Circuit
Temperature Range - Operating -40°C to 125°C
Mounting SMD (SMT)
Case / Package 10-DFN (3x3)
Win Source Part Number 1048703-ISL80103IRAJZ-TK
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian ISL80103IRAJZ-TK CAD Model

Description

The ISL80103IRAJZ-TK is an active integrated circuit voltage regulator from Intersil.

  • Status: Active
  • Category: Integrated circuit voltage regulator
  • Maximum Input Voltage: 6V
  • Nominal Output Voltage: 0.8V
  • Dropout Voltage-Max: 0.244V @ 3A
  • Operating Supply Current: 9mA to 12mA
  • Package: 10-DFN (3x3)
  • Operating Temperature Range: -40°C to 125°C
