MAX3232CDB Texas Instruments
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Tube/Rail
Status Active
Type Transceiver
Protocol RS232
Number of Drivers/Receivers 2/2
Duplex Full
Receiver Hysteresis 300mV
Data Rate 250kbps
Supply Voltage - Operating 3 V to 5.5 V
Temperature Range - Operating 0°C to 70°C
Mounting SMD (SMT)
Case / Package 16-SSOP
Win Source Part Number 082982-MAX3232CDB
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian MAX3232CDB CAD Model

Description

The MAX3232CDB from Texas Instruments is a high-performance, dual receiver/dual transmitter RS-232 Interface Device.

  • Operating Voltage: 3.0V to 5.5V
  • Feature: Low-power shutdown mode
  • Receivers Input: Can handle up to ±30V input
  • Transmitters Output: Can output up to ±5.5V, even when powered from a 3.0V power supply
  • Low-Power Shutdown Mode: 1µA with receivers active
  • Data Rates: Up to 250kbps
  • ESD Protection: ±15kV (human-body model) on its transmitter outputs and receiver inputs
  • Package: Thin shrink small-outline package (DB)
  • Operating Temperature Range: -40°C to +85°C
