MAX3232CDBR Texas Instruments
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Type Transceiver
Protocol RS232
Number of Drivers/Receivers 2/2
Duplex Full
Receiver Hysteresis 300mV
Data Rate 250kbps
Supply Voltage - Operating 3 V to 5.5 V
Temperature Range - Operating 0°C to 70°C
Mounting SMD (SMT)
Case / Package 16-SSOP
Win Source Part Number 021500-MAX3232CDBR
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Application Field Used in Computers & Computer Peripherals, Portable Devices, Sensing & Instrumentation, Wireless, Industrial
Family Name MAX3232
Introduction Date August 01, 2003
ECCN EAR99
Country of Origin Malaysia
Halogen Free Compliant
Estimated EOL Date 2031
Ultra Librarian 3D Model Ultra Librarian MAX3232CDBR CAD Model

Description

The MAX3232CDBR is a premium grade product from Texas Instruments, a renowned global semiconductor design and manufacturing company.

  • Product: Two-driver and two-receiver device
  • Category: Interface ICs, specifically transceivers
  • Operating Voltage: 3.0 V to 5.5 V
  • Function: RS-232 Interface IC
  • Data Rate: Up to 250 kbps
  • Power Consumption: Less than 1 µA in low-power shutdown mode
  • ESD Protection: Exceeding ±15 kV using the Human Body Model (HBM)
  • Compliance: Meets TIA/EIA-232-F requirements
  • Package: Surface-mount, 16-pin SSOP (Shrink Small Outline Package)
  • Operating Temperature Range: 0°C to 70°C
