Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Tube
Type Transceiver
Protocol RS232
Number of Drivers/Receivers 2/2
Duplex Full
Receiver Hysteresis 300mV
Data Rate 250kbps
Supply Voltage (V) 3V ~ 5.5V
Temperature Range - Operating 0°C ~ 70°C
Mounting Style SMD
Manufacturer Package 16-SOIC
Supplier Device Package 16-SOIC
Family Part Number MAX3232E
Manufacturer Pack Quantity 40
MSL Level 1 (Unlimited)
Win Source Part Number 1213061-MAX3232ECD
Manufacturer Homepage www.ti.com
Popularity Medium
Supply and Demand Status Limited
Application Field Used in Industrial, Computers & Computer Peripherals
Ultra Librarian 3D Model Ultra Librarian MAX3232ECD CAD Model

Description

Product Overview: MAX3232ECD by Texas Instruments

The MAX3232ECD is a highly integrated transceiver solution from Texas Instruments designed for bidirectional serial communication in applications that require voltage level translation from a 3.3V or 5V microcontroller to the RS-232 standard. This device is a part of the MAX3232 family, which is known for its reliability and flexibility in connecting serial devices such as modems, printers, and various industrial equipment to microcontrollers or microprocessors.

Key Features

  • Voltage Range: The MAX3232ECD operates from a single 3.0V to 5.5V power supply, making it versatile for use in systems with different logic level requirements.
  • Low-Power Consumption: With its low-power shutdown mode that reduces power consumption to 1µA, the device is suitable for battery-powered applications where power efficiency is crucial.
  • Data Rate: It supports data rates up to 250kbps, enabling fast data communication for a wide range of applications.
  • Electrostatic Discharge (ESD) Protection: The device features integrated ESD protection circuitry, safeguarding it against electrostatic discharges up to ±15kV, thus enhancing its robustness and reliability in harsh environments.
  • Transceiver Count: It includes two drivers and two receivers, providing the necessary components for full-duplex communication.

Applications

  • Battery-Powered Equipment
  • Handheld and Portable Devices
  • Data Cable Extensions
  • Industrial Control Systems
  • Point-of-Sale Systems

Package and Quality

The MAX3232ECD comes in a compact 16-pin SSOP (Shrink Small Outline Package) that is suitable for space-constrained applications. Texas Instruments ensures high manufacturing standards, providing a product that meets rigorous industry quality criteria. The device is RoHS compliant, adhering to environmental regulations and is suitable for use in a wide range of commercial and industrial temperature ranges.

Conclusion

The MAX3232ECD from Texas Instruments is a robust and versatile RS-232 transceiver, ideal for a myriad of applications that require reliable serial communication. Its low-power consumption, built-in ESD protection, and support for varying voltage levels make it an excellent choice for designers looking to interface with RS-232 data ports in a compact and efficient manner.
