OPA548FKTWT Real Image OPA548FKTWT Real Image1 OPA548FKTWT Real Image2 OPA548FKTWT Real Image3
Same model may have multiple batches, images only for reference.
OPA548FKTWT Real Image OPA548FKTWT Real Image1 OPA548FKTWT Real Image2 OPA548FKTWT Real Image3
OPA548FKTWT Real Image OPA548FKTWT Real Image1 OPA548FKTWT Real Image2 OPA548FKTWT Real Image3
Same model may have multiple batches, images only for reference.

OPA548FKTWT

Part No OPA548FKTWT
Manufacturer Texas Instruments
Catalog Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description IC OPAMP POWER 1MHZ DDPAK
Datasheet
OPA548FKTWT Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Amplifier Type Power
Number of Circuits 1
Slew Rate 10 V/μs
Gain Bandwidth Product (GBP) 1MHz
Current - Input Bias 100nA
Voltage - Input Offset 2mV
Operating Supply Current 17mA
Channel Output Current 5A
Supply Voltage - Operating 8 V to 60 V, ±4 V to 30 V
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package DDPAK/TO-263-7
Win Source Part Number 082034-OPA548FKTWT
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Application Field Used in Motor Drive & Control, Power Management, Test & Measurement, Audio
Ultra Librarian 3D Model Ultra Librarian OPA548FKTWT CAD Model

Description

The OPA548FKTWT is a high-voltage, high-current operational amplifier produced by Texas Instruments, a globally renowned technology company.

  • Output Current: Up to 10A
  • Supply Range: ±10V to ±50V
  • High Bandwidth: 3MHz
  • High Slew Rate: 10V/μs
  • Thermal Shutdown: Yes
  • Output Short-Circuit Protection: Yes
  • User-Programmable Current Limit: Yes
  • Operating Mode: Either inverting or non-inverting
  • Package: Standard 7-pin TO-220
