SN74AC00NSR Real Image SN74AC00NSR Real Image
Same model may have multiple batches, images only for reference.
SN74AC00NSR Real Image SN74AC00NSR Real Image
SN74AC00NSR Real Image SN74AC00NSR Real Image
Same model may have multiple batches, images only for reference.

SN74AC00NSR

Part No SN74AC00NSR
Manufacturer Texas Instruments
Catalog Logic - Gates and Inverters
Description IC GATE NAND 4CH 2-INP 14-SO
Datasheet
SN74AC00NSR Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Logic Type NAND Gate
Number of Circuits 4
Number of Inputs 2
Supply Voltage - Operating 2 V to 6 V
Current - Quiescent (Max) 2μA
Current - Output High, Low 24mA, 24mA
Logic Level - Low 0.9 V to 1.65 V
Logic Level - High 2.1 V to 3.85 V
Max Propagation Delay @ V, Max CL 8ns @ 5V, 50pF
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package 14-SOP
Dimension 14-SOIC (0.209", 5.30mm Width)
Win Source Part Number 065135-SN74AC00NSR
Popularity Medium
Supply and Demand Status Balance
Application Field Used in Industrial
Ultra Librarian 3D Model Ultra Librarian SN74AC00NSR CAD Model

Description

The SN74AC00NSR is an advanced high-speed CMOS device from Texas Instruments.

  • Type: quad 2-input positive-NAND gate
  • Voltage Range: 2 to 6 volts
  • Drive Capability: High
  • Noise Immunity: High
  • Technology: CMOS
  • Package: small-outline package
  • Compliance: RoHS compliant
