Product Overview: SN74ACT14DRG4 from Texas Instruments

The SN74ACT14DRG4 is a high-quality, Hex Schmitt-Trigger Inverter manufactured by Texas Instruments, designed for use in a wide range of digital electronics applications. This integrated circuit provides a robust solution for signal conditioning, especially in environments where noise is present, ensuring a clean and stable digital output.

Key Features

• Logic Type: The device features six independent Schmitt-Trigger inverters, which are designed to provide a hysteresis effect. This characteristic is particularly useful for transforming noisy input signals into sharp, clean digital outputs.
• Operating Voltage: The SN74ACT14DRG4 operates over a wide voltage range of 4.5V to 5.5V, making it compatible with standard TTL (Transistor-Transistor Logic) levels and ensuring easy integration into 5V systems.
• High-Speed Performance: With a typical propagation delay time of 8ns at 5V, this device is capable of high-speed operation, which is essential for fast-switching digital circuits.
• Drive Capability: The outputs can drive up to 24mA, providing sufficient current to drive multiple loads or for interfacing with other logic families.
• IC Package: The SN74ACT14DRG4 is offered in an SOIC-14 package, which is a small-outline integrated circuit package that is widely used and suitable for automated assembly processes.

Applications

With its versatile features, the SN74ACT14DRG4 is ideal for a variety of applications, including:

• Wave shaping and signal conditioning
• Glitch removal on digital lines
• Oscillator circuits
• Logic level conversion
• Pulse shaping

Quality and Reliability

Texas Instruments is renowned for its commitment to quality and reliability, and the SN74ACT14DRG4 is no exception. This device is fabricated using TI’s advanced Schottky process, ensuring high performance and long-term reliability for critical applications. Furthermore, it is specified for operation from -40°C to 85°C, accommodating a wide range of environmental conditions.

Whether you are designing consumer electronics, industrial control systems, or complex digital interfaces, the SN74ACT14DRG4 provides the performance and reliability you need to ensure your product's success.
