SN74AHC14DR Real Image SN74AHC14DR Real Image
Same model may have multiple batches, images only for reference.
SN74AHC14DR Real Image SN74AHC14DR Real Image
SN74AHC14DR Real Image SN74AHC14DR Real Image
Same model may have multiple batches, images only for reference.

SN74AHC14DR

Part No SN74AHC14DR
Manufacturer Texas Instruments
Catalog Logic - Gates and Inverters
Description IC HEX SCHMITT-TRIG INV 14-SOIC
Datasheet
SN74AHC14DR Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Logic Type Inverter
Number of Circuits 6
Number of Inputs 6
Features Schmitt Trigger
Supply Voltage - Operating 2 V to 5.5 V
Current - Quiescent (Max) 2μA
Current - Output High, Low 8mA, 8mA
Logic Level - Low 0.9 V to 1.65 V
Logic Level - High 2.2 V to 3.85 V
Max Propagation Delay @ V, Max CL 10.6ns @ 5V, 50pF
Temperature Range - Operating -40°C to 125°C
Mounting SMD (SMT)
Case / Package 14-SOIC
Dimension 14-SOIC (0.154", 3.90mm Width)
Win Source Part Number 006537-SN74AHC14DR
Family Name SN74AHC14
Introduction Date July 01, 2011
ECCN EAR99
Country of Origin Malaysia, Mexico
Halogen Free Compliant
Estimated EOL Date 2028
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Application Field Used in Industrial
Ultra Librarian 3D Model Ultra Librarian SN74AHC14DR CAD Model

Description

The SN74AHC14DR is a high-performance, integrated circuit designed and manufactured by Texas Instruments, a world-renowned American technology company known for its high-quality semiconductor products.

  • Series: SN74
  • Function: Hex Schmitt-trigger inverter
  • Operating Voltage Range: 2V to 5.5V
  • Noise Immunity: Typically 1V over the full voltage range
  • Package: SOIC
  • Power Consumption: Low
  • Drive Capability: Up to 8mA @ 5V
