SN74AHCT14DBR

Part No SN74AHCT14DBR
Manufacturer Texas Instruments
Catalog Logic - Gates and Inverters
Description IC HEX SCHMITT-TRIG INV 14-SSOP / Inverter Schmitt Trigger 6-Element CMOS 14-Pin SSOP T/R
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits (ICs)
Manufacturer Texas Instruments
Series 74AHCT
Packaging Reel package
Logic Type Inverter
Number of Circuits 6
Number of Inputs 6
Features Schmitt Trigger
Operating Supply Voltage 4.5 V ~ 5.5 V
Maximum Quiescent Current 2μA
Current - Output High, Low 8mA, 8mA
Logic Level - Low 0.5 V ~ 0.6 V
Logic Level - High 1.9 V ~ 2.1 V
Max Propagation Delay @ V, Max CL 8ns @ 5V, 50pF
Operating Temperature Range -40°C ~ 85°C
Mounting SMD
Manufacturer Package 14-SSOP
Package 14-SSOP (0.209", 5.30mm Width)
Win Source Part Number 794906-SN74AHCT14DBR
Popularity Medium
Supply and Demand Status Balance
Family Name SN74AHCT14
Introduction Date August 01, 2003
ECCN EAR99
Country of Origin Malaysia
Halogen Free Compliant
Estimated EOL Date 2031
Ultra Librarian 3D Model Ultra Librarian SN74AHCT14DBR CAD Model

Description

Product Overview: SN74AHCT14DBR

The SN74AHCT14DBR is a high-performance, hex schmitt-trigger inverter integrated circuit (IC) designed and manufactured by Texas Instruments (TI), a leader in semiconductor solutions. This device is part of TI's Advanced High-Speed CMOS (AHCT) family, which is known for its robustness and compatibility with TTL (Transistor-Transistor Logic) levels.

Each inverter in the SN74AHCT14DBR features a Schmitt-trigger action, which enhances the noise immunity and transforms slowly changing input signals into sharply defined jitter-free output signals. This characteristic is particularly beneficial in applications where noise is present on the input signal lines, or when slow-rising or falling edges are encountered.

Key Features

  • Logic Type: Hex Schmitt-Trigger Inverters
  • Supply Voltage Range: 4.5V to 5.5V
  • Operating Temperature: -40°C to 85°C
  • Logic Level Compatibility: TTL
  • Output Current: ±8 mA
  • Mounting Type: Surface Mount
  • Package: SSOP (Shrink Small Outline Package)
  • Pin Count: 14

The SN74AHCT14DBR features a wide operating voltage range that makes it suitable for interfacing with 5V systems. With its operating temperature range from -40°C to 85°C, it ensures reliable performance in diverse environments and applications.

Applications

The versatility of the SN74AHCT14DBR allows it to be used in a wide array of electronic circuits and systems. Common applications include:

  • Wave shaping and noise filtering
  • Signal processing
  • Glitch-free clock circuits
  • Logic circuits
  • Pulse shaping
  • Interface circuits

With its robust design and compatibility with TTL levels, the SN74AHCT14DBR is an excellent choice for designers who require a reliable solution for signal conditioning and logic inversion tasks.

The SN74AHCT14DBR is available in a compact SSOP package, which is ideal for space-constrained applications. Its surface-mount design allows for efficient assembly on printed circuit boards (PCBs), making it a popular choice for modern electronic products.

Overall, the SN74AHCT14DBR from Texas Instruments represents a blend of performance, flexibility, and reliability, providing engineers with a trusted component for their digital logic needs.
