SN74LVC00ANS

Part No SN74LVC00ANS
Manufacturer Texas Instruments
Catalog Logic - Gates and Inverters
Description IC GATE NAND 4CH 2-INP 14-SO / IC Channel
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Integrated Circuits (ICs) - Logic - Gates and Inverters
Mfr Texas Instruments
Series 74LVC
Package Bulk
Product Status Active
Base Product Number 74LVC00
Standard Package 1,902 pcs
MSL Level 3 (168 Hours)
REACH Status Vendor Undefined
ECCN EAR99
HTSUS 8542.39.0001
Win Source Part Number 727126-SN74LVC00ANS
Ultra Librarian 3D Model Ultra Librarian SN74LVC00ANS CAD Model

Description

The SN74LVC00ANS from Texas Instruments is a high-performance, quadruple 2-input positive-NAND gate integrated circuit. This device is designed to operate from 1.65 V to 5.5 V, making it suitable for a wide range of applications including portable electronics, computing devices, and high-speed interfacing within telecommunications. Its LVC (Low-Voltage CMOS) technology ensures low power consumption while maintaining high-speed operation.

Key Features

  • Logic Type: NAND Gate
  • Number of Circuits: 4
  • Inputs per Circuit: 2
  • Operating Voltage Range: 1.65 V to 5.5 V
  • Output Current: -32 mA / 32 mA
  • Propagation Delay Time: 3.4 ns at 3.3 V, 2.6 ns at 5 V
  • Operating Temperature Range: -40°C to 85°C
  • Mounting Type: Surface Mount
  • Package / Case: SOP-14

Performance Advantages

The SN74LVC00ANS offers excellent performance with its high-speed operation and low power consumption. Its propagation delay is minimized, making it an ideal choice for high-frequency applications. The device is also characterized for operation from -40°C to 85°C, ensuring reliability in a range of environmental conditions.

Applications

Due to its versatile power range and high-speed performance, the SN74LVC00ANS is well-suited for a variety of applications, including:

  • Smartphones and Tablets
  • Personal Computers and Servers
  • Portable Gaming Devices
  • Networking Equipment
  • Industrial Control Systems
  • Consumer Electronics

Quality and Reliability

Texas Instruments is known for its commitment to quality and reliability, and the SN74LVC00ANS is no exception. It is designed to meet the stringent requirements of the most demanding applications, ensuring consistent performance and durability.
