Product Overview: SN74LVC1G14DBVRG4

The SN74LVC1G14DBVRG4 is a high-performance, single Schmitt-trigger inverter designed and manufactured by Texas Instruments, a leader in semiconductor solutions. This integrated circuit (IC) is a part of the 74LVC family and is fabricated with advanced silicon-gate CMOS technology to provide a device that has both high-speed operation and the capability to handle 5V tolerant inputs.

Key Features

• Logic Type: Schmitt-trigger inverter
• Supply Voltage Range: 1.65V to 5.5V, allowing for use in a variety of logic systems and making it compatible with both 3.3V and 5V logic levels.
• Logic Level Translation: Capable of translating inputs between 1.8V and 5V without the need for external components.
• Output Drive Capability: Can drive up to 32mA at the output, providing good signal strength for connected devices.
• Propagation Delay: Fast propagation delay times, typically 2.9ns at 5V, 3.2ns at 3.3V, and 4.1ns at 1.8V, ensuring quick response times in high-speed applications.
• Temperature Range: Operational in a wide temperature range from -40°C to +125°C, suitable for industrial applications.
• Package: Available in a small 5-pin SOT-23 (DBV) package, ideal for space-constrained applications.
• RoHS Compliant: Meets environmental standards as it is lead-free and RoHS compliant.

Applications

The SN74LVC1G14DBVRG4 is versatile and can be used in a wide array of electronic applications. It's commonly found in:

• Wave shaping and noise filtering circuits
• Signal processing
• Glitch-free power-up / power-down circuitry
• Interface or level-shifting applications
• Portable and battery-powered electronics

Quality and Reliability

Texas Instruments is known for its commitment to quality, and the SN74LVC1G14DBVRG4 is no exception. Each device undergoes rigorous testing to ensure it meets the high standards that customers expect from TI products. This commitment to quality makes the SN74LVC1G14DBVRG4 a reliable choice for designers and engineers looking for a dependable Schmitt-trigger inverter for their next project.
