The SN74LVC1G240DBVR is a high-performance, single-bit buffer or driver from Texas Instruments. This advanced device is designed with the latest 3-state technology, which enables it to be used in a variety of applications. The product is crafted with a high drive capability of ±24mA at 3.3V. This ensures that it can function efficiently, even in high-speed systems.
The device features a wide operating voltage range of 1.65V to 5.5V. This makes it highly versatile and adaptable in different system environments. One of the key features of the SN74LVC1G240DBVR is its low power consumption. It operates with a maximum ICC of 10 µA in standby mode, making it an energy-efficient choice for low-power systems.
The SN74LVC1G240DBVR is also equipped with an Output Enable (OE) input that can disable the outputs to assume a high-impedance state. This feature ensures that the device can be connected directly to a bus-structured system without causing any potential damage.
Furthermore, the SN74LVC1G240DBVR is designed to be compatible with both 3.3V and 5V systems. This means it can be used in a mixed-voltage system environment without any issues. The device also supports down translation from 5V to 3.3V or 3.3V to 2.5V, and up translation from 2.5V or 3.3V to 5V, making it a truly flexible and versatile device.
The SN74LVC1G240DBVR comes in a small DBV package (SOT-23), which makes it ideal for space-constrained applications. It is also RoHS compliant and supports green manufacturing processes, thereby making it an environmentally friendly choice.
Overall, the SN74LVC1G240DBVR from Texas Instruments is a high-quality, high-performance single-bit buffer or driver that offers a wide range of features and benefits. Its high drive capability, low power consumption, wide operating voltage range, and compatibility with both 3.3V and 5V systems make it a reliable and efficient choice for a variety of applications.
