SN74LVC1G34DCKT - Single Buffer Gate
The SN74LVC1G34DCKT is a single buffer gate device designed and manufactured by Texas Instruments, a leader in semiconductor solutions. This high-performance, low-power device operates from a 1.65 V to 5.5 V supply, making it suitable for a variety of applications across multiple industries.
Key Features:
- Wide Operating Voltage Range: The device can operate with a supply voltage ranging from 1.65 V to 5.5 V, accommodating a variety of logic level requirements and offering design flexibility.
- Low Power Consumption: Its low power consumption makes it an ideal choice for battery-powered and low-power applications.
- High Drive: The SN74LVC1G34DCKT is capable of driving capacitive loads while maintaining signal integrity, thanks to its high-drive output.
- ESD Protection: Enhanced Electrostatic Discharge (ESD) protection shields the device from static damage, ensuring reliability and longevity.
- SC70 Packaging: The device is offered in an ultra-small SC70 package, which is optimal for space-constrained applications.
Applications:
The versatility of the SN74LVC1G34DCKT makes it an excellent choice for a wide array of applications. These include but are not limited to:
- Smartphones and portable electronics
- Computing peripherals and servers
- Industrial control systems
- Consumer electronics
- Medical devices
Technical Specifications:
Parameter
Value
Logic Type
Buffer/Line Driver
Number of Channels
1
Output Type
Push-Pull
Mounting Type
Surface Mount
Package / Case
SC-70-5
For detailed product specifications, technical documents, data sheets, and support resources, please visit the Texas Instruments website or contact their support team for assistance.
