The SN74LVC1G58DCKR is a versatile configurable multiple-function gate from Texas Instruments designed for operation in the advanced 1.65-V to 5.5-V V<sub>CC range. This makes it suitable for a wide array of applications, ranging from portable electronics to industrial systems, where low power consumption and high efficiency are paramount.

Key Features

• Configurable multiple-function capability, allowing for a variety of logical operations within a single chip.
• Support for 1.65-V to 5.5-V V<sub>CC operation, ensuring compatibility with low-voltage and standard TTL-level systems.
• Low power consumption, which is critical for battery-operated and power-sensitive applications.
• High drive capability, which enables the device to drive a high number of inputs without degradation in performance.
• Available in a compact SC70 package, which is ideal for space-constrained applications.

Applications

The SN74LVC1G58DCKR's flexible design and voltage range make it suitable for a diverse set of applications, including:

• Smartphones, tablets, and other portable devices where power efficiency is a necessity.
• Embedded systems requiring a variety of logic functions in a limited space.
• Industrial controls where robust performance across a range of operating conditions is needed.
• Consumer electronics that require reliable logic operations at varying voltage levels.

Technical Specifications

The device provides a multitude of logic functions, including AND, OR, NAND, NOR, XOR, XNOR, and more, through a combination of the A, B, and Y input pins. It is characterized for operation from -40°C to 85°C, ensuring reliability in a broad range of environments. The SN74LVC1G58DCKR also features Schmitt-trigger action at all inputs, which makes the circuit tolerant to slower input rise and fall times.

Ordering and Packaging

The SN74LVC1G58DCKR comes in a 6-pin SC70 package and is available in tape and reel form for automated assembly processes. The device's ordering number is SN74LVC1G58DCKR, which ensures you receive the genuine product manufactured by Texas Instruments.
