The SN75C1168NSR is a robust dual line driver and receiver pair from Texas Instruments, designed to satisfy the stringent requirements of the RS-232 communication protocol. This integrated circuit is specifically engineered to operate with a single 5V power supply, making it a versatile solution for serial data transmission in a wide array of applications.

Key Features

• Interface Type: The device adheres to the RS-232 standard, ensuring compatibility with many serial communication systems.
• Dual Line: It incorporates a dual driver and receiver, which allows for simultaneous transmission and reception of data, enhancing communication efficiency.
• Power Supply: Optimized for a single 5V power supply, the SN75C1168NSR is ideal for systems where power availability is limited.
• Low Power Consumption: The device is designed for low power consumption, which is crucial for battery-powered or energy-sensitive applications.
• High Data Rate: Capable of supporting data rates of up to 120 kbps, it is suitable for applications requiring fast data transfer.
• Electrostatic Discharge (ESD) Protection: It offers built-in ESD protection, ensuring the device's resilience against static electricity damages.

Applications

Due to its reliability and versatility, the SN75C1168NSR is suitable for a broad range of applications, including:

• Point-of-sale terminals
• Telecommunication systems
• Data acquisition systems
• Industrial control equipment
• Networking equipment and modems

Product Specifications

The SN75C1168NSR comes in an SOP (Small Outline Package) form factor, making it compact and suitable for space-constrained applications. The device operates within a temperature range of -40°C to 85°C, ensuring reliability across various environmental conditions. Additionally, it is compliant with RoHS (Restriction of Hazardous Substances), which makes it an environmentally friendly choice for electronic systems.

Ordering Information

To order the SN75C1168NSR or to obtain more information about pricing and availability, please visit the Texas Instruments official website or contact an authorized distributor. Ensure that you are procuring the correct part number to match your design specifications and requirements.
