Overview of the TLV1117-25CDCYRG3 Voltage Regulator

The TLV1117-25CDCYRG3 is a robust low-dropout regulator (LDO) designed by Texas Instruments, engineered to deliver a fixed output voltage of 2.5V with an output current capacity of up to 800mA. This product is a part of the TLV1117 series, which is known for its reliability and performance in a wide array of applications.

Key Features

• Output Voltage: The device provides a stable 2.5V output, which is essential for consistent performance in electronic circuits.
• High Output Current: With an ability to deliver up to 800mA, it can power a wide range of components, from microcontrollers to analog devices.
• Low Dropout: The LDO's low dropout voltage allows it to operate efficiently even when the supply voltage is very close to the output voltage, minimizing power loss and heat generation.
• Thermal Protection: The built-in thermal shutdown feature protects the device from overheating, ensuring safe operation under varying conditions.
• Overcurrent Protection: The current limit feature safeguards the regulator and the load from damage in the event of a short circuit or excessive load.
• Stable with Low ESR Capacitors: The TLV1117-25CDCYRG3 is stable with ceramic capacitors, which reduces the need for bulky tantalum or aluminum electrolytic types.

Applications

The TLV1117-25CDCYRG3 is versatile and can be used in various applications, including:

• Power supplies for microcontrollers and digital logic
• Post-regulation for switching power supplies
• Battery-powered devices
• Consumer electronics
• Peripheral power supplies

Package and Quality

Encased in a SOT-223 package, the TLV1117-25CDCYRG3 is not only compact but also offers a robust design for surface-mount technology, facilitating easy integration into a wide range of electronic products. Its production adheres to Texas Instruments' stringent quality standards, ensuring high reliability and performance consistency across applications.

The TLV1117-25CDCYRG3 from Texas Instruments represents a reliable and efficient solution for low-voltage, high-current applications, making it an excellent choice for designers looking to enhance the performance and stability of their power management systems.
