The TLV2374ID is a high-precision operational amplifier from Texas Instruments, designed to meet the requirements of various signal conditioning and sensor amplification tasks in a wide array of electronic applications. This op-amp features Rail-to-Rail input and output swing, along with a low input bias current, making it an ideal choice for battery-powered and portable devices.

Key Features

• Low Power Consumption: With a supply current of just 165 µA per channel, the TLV2374ID is optimized for power-sensitive applications.
• Rail-to-Rail Operation: The input and output can swing within millivolts of the supply rails, ensuring maximum dynamic range in your circuit.
• Wide Supply Range: It operates from a single supply voltage ranging from 2.7V to 16V or dual supplies of ±1.35V to ±8V, granting flexibility in various design architectures.
• High Output Drive Capability: Capable of driving loads as low as 600Ω, the TLV2374ID can be used in a variety of applications that require a robust output drive.
• Micro-Power Shutdown Mode: An additional feature is the shutdown mode which reduces the current consumption to be as low as 0.5 µA per channel, further enhancing its suitability for battery-operated devices.

Applications

The TLV2374ID is versatile and can be used in numerous applications, including:

• Portable and battery-operated equipment
• Medical instrumentation
• Sensor conditioning
• Analog filters
• Automotive electronics
• Process control systems

Quality and Reliability

Encased in an SOIC-14 package, the TLV2374ID is built to uphold the highest standards of quality and reliability that Texas Instruments is known for. Its operational temperature range from -40°C to +125°C ensures performance across a broad spectrum of environmental conditions.

Ordering Information

To order the TLV2374ID or to obtain more information, datasheets, and support, visit the Texas Instruments official website or contact your local authorized distributor.
