The TLV70228DSER is a high-performance, low-dropout (LDO) voltage regulator from Texas Instruments (TI), designed to meet the demanding needs of modern electronic devices. This regulator offers a fixed output voltage of 2.8V, which is ideal for providing a stable power supply to sensitive components such as microcontrollers, sensors, and RF circuits.

Key Features

• High Accuracy: The TLV70228DSER provides excellent regulation with a low dropout voltage, ensuring a consistent 2.8V output even when the input voltage is close to the output voltage. This is crucial for maintaining performance in battery-operated devices where the input voltage can vary over time.
• Low Power Consumption: With a quiescent current of just 25 µA, this LDO is optimized for battery-powered applications, helping to extend battery life and reduce power waste.
• Stable Operation: The device is stable with ceramic capacitors, which are preferred in modern electronic designs for their small size and reliability.
• Built-in Protection: The TLV70228DSER includes features such as over-current protection and thermal shutdown to safeguard the device and connected components from damage due to abnormal operating conditions.

Applications

The TLV70228DSER is ideal for a broad range of applications, including but not limited to:

• Portable and battery-powered devices
• Wireless communication systems
• Power supply for sensors and microcontrollers
• Healthcare and medical equipment
• Smart home devices

Technical Specifications

The device comes in a compact, 6-pin WSON package with a nominal output voltage of 2.8V. It supports an input voltage range from 2.0V to 5.5V, which provides flexibility in various power supply configurations. The maximum output current is 300 mA, making it suitable for a wide range of low-power applications.

Quality and Reliability

As with all Texas Instruments products, the TLV70228DSER is manufactured to the highest quality standards, ensuring reliability and performance in the most demanding conditions. TI's commitment to quality makes this LDO voltage regulator a trusted choice for engineers and designers across all sectors of electronics.
