Products specifications

Categories Sensors, Transducers
Manufacturer Texas Instruments
Packaging Reel - TR
Trip Temperature Threshold Hot
Switching Temperature Programmable
Accuracy ±6°C
Output Type Open Drain
Output Active Low
Output Function /OverTemp, VTemp
Selectable Hysteresis Yes
Features Trip Test
Operating Supply Voltage 1.8 V ~ 18 V
Operating Supply Current 110μA
Operating Temperature Range -40°C ~ 150°C
Mounting SMD
Package SOT-23-6
Manufacturer Package SOT-23-6
Win Source Part Number 1270792-TMP300BIDBVR
Manufacturer Homepage www.ti.com
Popularity Medium
Supply and Demand Status Limited
Family Name TMP300
Introduction Date November 01, 2010
Halogen Free Compliant
Estimated EOL Date 2028
Ultra Librarian 3D Model Ultra Librarian TMP300BIDBVR CAD Model

Description

The TMP300BIDBVR is a highly precise temperature switch from Texas Instruments, designed to cater to a wide range of applications requiring temperature monitoring and control. This tiny, yet robust device comes in a 6-pin SOT-23 package, making it suitable for space-constrained applications.

Key Features

  • Accuracy: The TMP300 offers an impressive accuracy of ±1°C, ensuring reliable temperature readings for critical applications.
  • Adjustable Temperature Thresholds: Users can set the temperature thresholds according to their specific needs, providing versatility across different systems.
  • Low Power Consumption: With a quiescent current of just 50 μA, the TMP300 is an energy-efficient solution for battery-powered devices.
  • Wide Operating Range: The device operates over a temperature range of -40°C to +125°C, suitable for a variety of environmental conditions.
  • Output Configuration: The TMP300 features an open-drain output, which allows for easy interfacing with other components and systems.

Applications

The TMP300BIDBVR is ideal for several applications, including but not limited to:

  • System Thermal Management
  • Environmental Monitoring
  • Battery Management Systems
  • Industrial Equipment
  • Consumer Electronics

Technical Specifications

Parameter Value Package Type SOT-23 Temperature Accuracy ±1°C Operating Temperature Range -40°C to +125°C Supply Voltage 2.7V to 5.5V Quiescent Current 50 μA Output Type Open-Drain

For engineers and designers looking for a reliable thermal switch, the TMP300BIDBVR from Texas Instruments provides a compact, accurate, and versatile solution. Its low power consumption and adjustable temperature threshold make it a go-to component for temperature-sensitive applications.
