The TPS54226PWPR, manufactured by Texas Instruments, is a highly efficient synchronous buck converter that is designed for use in a wide range of applications. This compact power management integrated circuit (PMIC) is capable of delivering up to 2A of continuous output current with input voltages ranging from 4.5V to 18V, making it a versatile choice for powering various electronic devices.

Key Features

• Adjustable Switching Frequency: The TPS54226PWPR offers an adjustable switching frequency from 340 kHz to 2.2 MHz, allowing designers to optimize the performance for specific applications.
• Integrated MOSFETs: The device includes two low R_DS(on) power MOSFETs, which helps to reduce the external component count and simplifies the design process.
• High Efficiency: With its advanced control features and low dropout operation, the TPS54226PWPR achieves high efficiency across a wide load range.
• Protection Features: The converter is equipped with a comprehensive set of protection features, including overcurrent protection (OCP), overvoltage protection (OVP), thermal shutdown (TSD), and undervoltage lockout (UVLO).
• Power Good (PG) Output: This feature provides a power-good signal when the output voltage is within the nominal range, which is useful for sequence control in complex systems.

Applications

The TPS54226PWPR is suitable for a variety of applications, including:

• Consumer Electronics
• Networking Equipment
• Point-of-Load (POL) Power Supplies
• Industrial and Automotive Systems

Package and Availability

The TPS54226PWPR comes in a 14-pin HTSSOP (PWP) package with PowerPAD™, which is designed for enhanced thermal performance. The device is available for purchase from Texas Instruments and authorized distributors. For detailed specifications, application notes, and design resources, interested parties can visit the Texas Instruments website or contact their sales representative.
