TPS61230DRCR

Part No TPS61230DRCR
Manufacturer Texas Instruments
Catalog PMIC - Voltage Regulators - DC DC Switching Regulators
Description IC REG BOOST ADJ 4A SYNC 10SON / Conv DC-DC 2.3V to 5.5V Synchronous Step Up Single-Out 2.5V to 5.5V 2.1A 10-Pin VSON EP T/R
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Purpose Step-Up
Topology Boost
Output Type Adjustable
Number of Outputs 1
Minimum Input Voltage 2.3V
Maximum Input Voltage 5.5V
Nominal Output Voltage (Min/Fixed) 2.5V
Maximum Output Voltage 5.5V
Output Current 4A (Switch)
Frequency - Switching 2MHz
Synchronous Rectifier Yes
Temperature Range - Operating -40°C to 125°C (TJ)
Mounting SMD (SMT)
Case / Package 10-VSON (3x3)
Win Source Part Number 034297-TPS61230DRCR
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Quantity per package 3k pcs
Family Name TPS61230
Introduction Date April 05, 2014
ECCN EAR99
Country of Origin Philippines
Halogen Free Compliant
Estimated EOL Date 2031
Ultra Librarian 3D Model Ultra Librarian TPS61230DRCR CAD Model

Description

The TPS61230DRCR is a high-efficiency, synchronous boost converter designed and manufactured by Texas Instruments. This advanced power solution is engineered to deliver a stable and efficient voltage conversion for a variety of applications, including portable devices, battery-powered equipment, and any system requiring a higher voltage from a lower voltage source.

Key Features

  • Wide Input Voltage Range: The TPS61230DRCR operates with an input voltage range from 2.3V to 5.5V, making it versatile for use with single-cell lithium-ion or other battery chemistries.
  • Adjustable Output Voltage: Users can adjust the output voltage from 2.5V to 12V to suit various application requirements, ensuring compatibility with a range of devices.
  • High-Efficiency Synchronous Boost: Its synchronous boost topology provides higher efficiency compared to non-synchronous solutions, which is critical for maximizing battery life in portable applications.
  • Integrated Power Switches: The device includes two integrated power switches, which helps minimize the external component count and reduces the overall solution size.
  • Protection Features: It comes with built-in over-temperature and over-current protection, safeguarding the device and the load from potential damage due to abnormal operating conditions.

Applications

  • Portable and battery-powered electronics
  • Power banks and USB-powered devices
  • Energy harvesting and solar applications
  • Wireless speakers and audio devices
  • Handheld medical equipment

Package and Availability

The TPS61230DRCR is offered in a compact 10-pin SON package, designed for space-constrained applications. Its small footprint does not compromise on performance, providing a robust power solution in a minimal package. The device is available for purchase through Texas Instruments' official distributors, and detailed technical documentation, including datasheets and application notes, can be accessed through the Texas Instruments website.

With its combination of efficiency, versatility, and protection features, the TPS61230DRCR is an excellent choice for designers looking to enhance the power management capabilities of their next project.
