TPS62040DGQR

Part No TPS62040DGQR
Manufacturer Texas Instruments
Catalog PMIC - Voltage Regulators - DC DC Switching Regulators
Description Conv DC-DC 2.5V to 6V Synchronous Step Down Single-Out 0.7V to 6V 1.2A 10-Pin HVSSOP EP T/R / IC REG BUCK ADJ 1.2A SYNC 10MSOP
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Purpose Step-Down
Topology Buck
Output Type Adjustable
Number of Outputs 1
Minimum Input Voltage 2.5V
Maximum Input Voltage 6V
Nominal Output Voltage (Min/Fixed) 0.7V
Maximum Output Voltage 6V
Output Current 1.2A
Frequency - Switching 1.25MHz
Synchronous Rectifier Yes
Temperature Range - Operating -40°C to 85°C (TA)
Mounting SMD (SMT)
Case / Package 10-MSOP-PowerPad
Win Source Part Number 034324-TPS62040DGQR
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Application Field Used in Consumer Electronics, Communications & Networking, Computers & Computer Peripherals, Portable Devices
Family Name TPS62040
Introduction Date July 01, 2004
ECCN EAR99
Country of Origin China
Halogen Free Compliant
Estimated EOL Date 2031
Ultra Librarian 3D Model Ultra Librarian TPS62040DGQR CAD Model

Description

Product Overview: TPS62040DGQR by Texas Instruments

The TPS62040DGQR from Texas Instruments is a highly efficient synchronous step-down DC/DC converter belonging to the esteemed family of power management integrated circuits. This product is specifically designed to cater to portable and space-constrained applications, providing a compact, reliable solution for power conversion.

With an input voltage range of 2.5V to 6.0V, the TPS62040DGQR is versatile and well-suited for operating from a single lithium-ion battery or other power supplies within its voltage range. It supports an adjustable output voltage from 0.7V to the maximum input voltage, allowing for a wide range of output configurations to match specific circuit requirements.

This converter boasts a high efficiency of up to 95%, which is achieved through its synchronous step-down regulator topology. The low on-resistance of its internal MOSFETs minimizes power loss and helps to extend battery life in portable devices. Moreover, the TPS62040DGQR operates at a fixed switching frequency of 1.2MHz, enabling the use of small surface-mount inductors and capacitors, which further contributes to a reduced footprint on the PCB.

The device comes in a compact 10-pin MSOP PowerPad package, designated by the DGQR suffix, providing excellent thermal performance in a small form factor. This package is particularly useful for thermal management in space-constrained applications.

Additional features of the TPS62040DGQR include over-temperature protection and over-current protection, which safeguard the device and the system it powers from adverse conditions. The device also has a Power Save Mode, which enhances efficiency at light loads, and a 100% duty cycle for low-dropout operation.

Texas Instruments' commitment to quality and performance is evident in the TPS62040DGQR, making it an ideal choice for designers looking to implement an efficient power management solution in their next project. Whether it's for handheld devices, wireless peripherals, or other portable electronics, this DC/DC converter is engineered to deliver reliable performance in a variety of applications.
