TPS79333DBVRQ1

Part No TPS79333DBVRQ1
Manufacturer Texas Instruments
Catalog PMIC - Voltage Regulators - Linear
Description IC REG LDO 3.3V 0.2A SOT23-5
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Output Type Fixed
Number of Regulators 1
Maximum Input Voltage 5.5V
Nominal Output Voltage (Min/Fixed) 3.3V
Dropout Voltage-Max 0.18V @ 200mA
Output Current 200mA
Operating Supply Current 220μA
PSRR 70dB to 43dB (100Hz to 100kHz)
Control Features Enable
Protection Features Over Current, Over Temperature, Reverse Polarity, Under Voltage Lockout (UVLO)
Temperature Range - Operating -40°C to 125°C
Regulator Topology Positive Fixed
Output Voltage 3.3V
Voltage - Dropout (Typical) 0.102V @ 200mA
Mounting SMD (SMT)
Case / Package SOT-23-5
Win Source Part Number 083972-TPS79333DBVRQ1
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian TPS79333DBVRQ1 CAD Model

Description

Product Overview: TPS79333DBVRQ1 from Texas Instruments

The TPS79333DBVRQ1 is a high-performance, low-dropout (LDO) voltage regulator designed specifically for automotive and industrial applications. Manufactured by Texas Instruments, this regulator offers a stable and reliable power supply solution, particularly suited for noise-sensitive circuits that require a low voltage supply.

Key Features

  • Output Voltage: The device provides a fixed output voltage of 3.3V, which is ideal for powering microcontrollers, sensors, and other digital ICs.
  • High Accuracy: The output voltage is highly accurate, with a precision of 2%, ensuring that the connected components receive a consistent supply.
  • Low Dropout: With a very low dropout voltage, this LDO can maintain regulation with minimal difference between the input and output voltages, making it efficient in battery-operated devices.
  • Current Rating: The TPS79333DBVRQ1 can deliver up to 200mA of continuous output current, catering to a wide range of low-power applications.
  • Thermal Shutdown: It includes a thermal shutdown feature that protects the device from overheating, enhancing system reliability.
  • Overcurrent Protection: Built-in overcurrent protection safeguards the device and the load from damage due to excessive current draw.
  • Low Noise: This regulator is designed to minimize output noise, making it suitable for RF and precision analog circuits.
  • Package: The device is offered in a small, surface-mount SOT-23 package, which is perfect for space-constrained applications.
  • Automotive Grade: As a Q1-grade component, it meets the stringent quality and reliability standards required for automotive applications.

Applications

The TPS79333DBVRQ1 is versatile and can be used in a variety of applications, such as:

  • Automotive infotainment and telematics systems
  • Power supplies for sensors and ADAS components
  • Industrial control systems
  • Portable and battery-powered electronics
  • Healthcare and medical equipment

With its robust feature set, the TPS79333DBVRQ1 from Texas Instruments is a reliable choice for designers looking to enhance the performance and stability of their power management systems in automotive and industrial environments.
