CUS05S40,H3F Toshiba Semiconductor and Storage CUS05S40,H3F real image15275
Same model may have multiple batches, images only for reference.
CUS05S40,H3F Toshiba Semiconductor and Storage CUS05S40,H3F real image15275
CUS05S40,H3F Toshiba Semiconductor and Storage CUS05S40,H3F real image15275
Same model may have multiple batches, images only for reference.

CUS05S40,H3F

Part No CUS05S40,H3F
Manufacturer Toshiba Semiconductor and Storage
Catalog Diodes, Rectifiers - Single
Description DIODE SCHOTTKY 40V 500MA USC
Datasheet
CUS05S40,H3F Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Toshiba Semiconductor and Storage
Packaging Reel - TR
Status Active
Diode Type Schottky
Voltage - DC Reverse (Vr) (Max) 40V
Current - Average Rectified (Io) 500mA
Voltage - Forward (Vf) (Max) @ If 350mV @ 100mA
Speed(Frequency) Fast Recovery = 200mA (Io)
Current - Reverse Leakage @ Vr 30μA @ 10V
Capacitance @ Vr, F 42pF @ 0V, 1MHz
Mounting SMD (SMT)
Case / Package USC
Operating Temperature - Junction 125°C (Max)
Win Source Part Number 1030843-CUS05S40,H3F
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian CUS05S40,H3F CAD Model

Description

The Toshiba Semiconductor and Storage CUS05S40,H3F is a high-performance Schottky diode designed for use in various electronic devices, such as power supplies, automotive applications, and computers.

  • Maximum Reverse Voltage: 40V
  • Average Rectified Current: 500mA
  • Package: USC
