The RN49A2,LF(CT is a silicon PNP epitaxial planar transistor manufactured by Toshiba Semiconductor and Storage. It is designed for amplifier and switching applications in electronic circuits.

Applications

• Amplifier circuits
• Switching circuits
• Inverter circuits
• Portable devices
• General purpose applications

Features

• Low collector saturation voltage
• High collector current capability
• Small package size
• Lead-free (LF) package
• RoHS compliant

Benefits

• Efficient switching performance.
• Suitable for high-current applications.
• Enables compact circuit designs.
• Environmentally friendly due to lead-free and RoHS compliance.
• Easy to integrate into automated assembly processes.

Specifications

The RN49A2,LF(CT has a collector-emitter voltage of -20V, a collector current of -0.3A, and a power dissipation of 0.2W. Its collector saturation voltage is typically -0.15V at -0.1A. The current gain (hFE) ranges from 85 to 300. The operating temperature range is -55°C to +150°C. It is available in a SOT-23 (SMT3) package. This transistor is designed for both amplification and switching, making it a versatile component.

This PNP transistor provides good performance characteristics for various applications. The low saturation voltage helps minimize power losses in switching applications. The SOT-23 package allows for surface mounting, simplifying PCB assembly. The device is designed for automated placement and soldering, reducing manufacturing costs. Its small size and reliable performance make it suitable for portable and space-constrained applications.
