The SSM3J112TU TE85L is a P-channel MOSFET from Toshiba Semiconductor and Storage, designed for load switching and power management in portable applications. The TE85L suffix indicates a specific tape and reel packaging for automated assembly. The device is characterized by low on-resistance, fast switching speeds and a compact footprint.

Applications:

• Load Switching: Used in portable devices such as smartphones, tablets and wearables to control power to different circuits.
• DC-DC Conversion: Employed in step-up and step-down DC-DC converters for voltage regulation.
• Power Management Circuits: Integrated into battery management systems (BMS) to efficiently manage power distribution.
• Portable Consumer Electronics: Suitable for various battery-powered consumer devices.
• Solid State Relays: Acts as a switch element in applications requiring solid state relays.

Features:

• Low On-Resistance (RDS(on)): Minimizes power losses and enhances overall efficiency.
• Fast Switching Speed: Allows for efficient operation in high frequency applications.
• Low Gate Charge (Qg): Reduces drive power requirements.
• Small Surface Mount Package: Enables compact design and efficient board space utilization.
• TE85L Packaging: Specifically designed for automated assembly processes.

Benefits:

• Improved Efficiency: Low RDS(on) minimizes power dissipation, extending battery life in portable devices.
• Compact Design: Small footprint enables integration into space-constrained designs.
• Enhanced Thermal Performance: Minimizes heat generation during operation.
• Simplified Assembly: TE85L packaging supports automated pick-and-place processes.
• Increased Reliability: Stable operation under various environmental conditions.

Additional Details:

The SSM3J112TU TE85L operates at low voltage, making it suitable for battery-powered devices. It adheres to RoHS compliance for environmental regulations. The drain-source voltage (VDSS) and gate-source voltage (VGSS) ratings should be considered for safe operation. This MOSFET is frequently found in battery-powered devices due to its low power consumption and small size. The TE85L indicates it comes on tape and reel for pick and place machines on a production line.
