TB62747AFG(O,EL) Toshiba Semiconductor and Storage TB62747AFG(O,EL) label picture 2 TB62747AFG(O,EL) real image7040 TB62747AFG(O,EL) real image TB62747AFG(O,EL) label picture
Same model may have multiple batches, images only for reference.
TB62747AFG(O,EL) Toshiba Semiconductor and Storage TB62747AFG(O,EL) label picture 2 TB62747AFG(O,EL) real image7040 TB62747AFG(O,EL) real image TB62747AFG(O,EL) label picture
TB62747AFG(O,EL) Toshiba Semiconductor and Storage TB62747AFG(O,EL) label picture 2 TB62747AFG(O,EL) real image7040 TB62747AFG(O,EL) real image TB62747AFG(O,EL) label picture
Same model may have multiple batches, images only for reference.

TB62747AFG(O,EL)

Part No TB62747AFG(O,EL)
Manufacturer Toshiba Semiconductor and Storage
Catalog PMIC - LED Drivers
Description IC LED DVR 16CH CC 24SSOP
Datasheet
TB62747AFG(O,EL) Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Toshiba Semiconductor and Storage
Packaging Reel - TR
Status Obsolete(EOL)
Type Linear
Topology Shift Register
Internal Switch(s) Yes
Number of Outputs 16
Operating Input Voltage(Min) 3V
Maximum Supply Voltage 5.5V
Output Voltage 26V
Channel Output Current 45mA
Temperature Range - Operating -40°C to 85°C (TA)
Mounting SMD (SMT)
Case / Package 24-SSOP
Win Source Part Number 083916-TB62747AFG(O,EL)
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian TB62747AFG(O,EL) CAD Model

Description

The TB62747AFG(O,EL) is a shift register IC with 16 outputs.

  • Channel Output Current: 45mA
  • Output Voltage: 26V
  • Minimum Input Voltage: 3V
  • Maximum Supply Voltage: 5.5V
  • Package: 24-SSOP
  • Status: obsolete (EOL)
  • Usage: commonly used part
