TLP184(GB-TPL,SE Toshiba Semiconductor and Storage TLP184(GB-TPL,SE Real Image
Same model may have multiple batches, images only for reference.
TLP184(GB-TPL,SE Toshiba Semiconductor and Storage TLP184(GB-TPL,SE Real Image
TLP184(GB-TPL,SE Toshiba Semiconductor and Storage TLP184(GB-TPL,SE Real Image
Same model may have multiple batches, images only for reference.

TLP184(GB-TPL,SE

Part No TLP184(GB-TPL,SE
Manufacturer Toshiba Semiconductor and Storage
Catalog Optoisolators - Transistor, Photovoltaic Output
Description OPTOISO 3.75KV TRANS 6-SO 4 LEAD
Datasheet
TLP184(GB-TPL,SE Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Toshiba Semiconductor and Storage
Packaging Reel - TR
Status Active
Number of Channels 1
Isolation Voltage 3750Vrms
Minimum DC Current Transfer Ratio 100% @ 5mA
Maximum DC Current Transfer Ratio 600% @ 5mA
Switching Turn-On and Turn-Off Time 3μs, 3μs
Rise and Fall Time 2μs, 3μs
Input Type AC, DC
Output Type Transistor
Maximum Output Voltage 80V
Channel Output Current 50mA
Forward Voltage 1.25V
Continuous forward current- Max 50mA
Vce Saturation (Max) 300mV
Temperature Range - Operating -55°C to 110°C
Mounting SMD (SMT)
Case / Package 6-SO, 4 Lead
Win Source Part Number 1108849-TLP184(GB-TPL,SE
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian TLP184(GB-TPL,SE CAD Model

Description

The Toshiba Semiconductor and Storage TLP184(GB-TPL,SE) is a transistor output type optocoupler.

  • Input Signal: AC and DC
  • Channel Count: 1
  • Minimum DC Current Transfer Ratio: 100% @ 5mA
  • Maximum DC Current Transfer Ratio: 600% @ 5mA
  • Switching Turn-On Time: 3μs
  • Switching Turn-Off Time: 3μs
  • Rise Time: 2μs
  • Fall Time: 3μs
  • Forward Voltage: 1.25V
  • Vce Saturation (Max): 300mV
  • Isolation Voltage: 3750Vrms
  • Applications: High voltage applications
  • Package: 6-SO, 4 lead
  • Maximum Output Voltage: 80V
  • Continuous Forward Current: 50mA
  • Application: Isolators
