TLP2361(V4-TPL,E

Name: TLP2361(V4-TPL,E
Brand: Toshiba Semiconductor and Storage
SKU: 797044
Availability: InStock
Rating: 4.85 (162 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	TLP2361(V4-TPL,E
Manufacturer	Toshiba Semiconductor and Storage
Catalog	Optoisolators - Logic Output
Description	OPTOISO 3.75KV PSH PULL SO6-5 / Optocoupler Logic-Out Totem-Pole DC-IN 1-CH 5-Pin SO T/R
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Isolators
Manufacturer	Toshiba Semiconductor and Storage
Packaging	Reel package
Number of Channels	1
Inputs - Side 1/Side 2	1/0
Voltage - Isolation	3750Vrms
Common Mode Transient Immunity (Minimum)	20kV/μs
Input Type	DC
Output Type	Push-Pull, Totem Pole
Output Current per Channel	10mA
Data Rate	15MBd
Propagation Delay tpLH / tpHL (Maximum)	80ns, 80ns
Rise / Fall Time (Typ)	3ns, 3ns
Voltage - Forward (Vf) (Typ)	1.5V
Current - DC Forward (If) (Maximum)	10mA
Operating Supply Voltage	2.7 V ~ 5.5 V
Operating Temperature Range	-40°C ~ 125°C
Mounting	SMD
Package	6-SOIC (0.179", 4.55mm Width) 5 Leads
Manufacturer Package	6-SO, 5 Lead
Win Source Part Number	797044-TLP2361(V4-TPL,E
Popularity	Medium
Supply and Demand Status	Limited
Family Name	TLP2361
ECCN	EAR99
Country of Origin	Thailand
Estimated EOL Date	2031
Ultra Librarian 3D Model	Ultra Librarian TLP2361(V4-TPL,E CAD Model

Alternative Products

Description

The TLP2361(V4-TPL,E) is an isolator component manufactured by Toshiba Semiconductor and Storage.

Output Type: Push-pull, Totem Pole
Operating Supply Voltage: 2.7 V ~ 5.5 V
Data Rate: 15MBd
Voltage Isolation: 3750Vrms
Mounting: SMD
Package: 6-SOIC (0.179", 4.55mm Width) 5 Leads
Popularity: Medium
Supply and Demand Status: Limited
Common Mode Transient Immunity (Minimum): 20kV/μs
