TLP291-4 Toshiba Semiconductor and Storage TLP291-4 real image7472 TLP291-4 real image7473 TLP291-4 Real Image1 TLP291-4 Real Image2 TLP291-4 Real Image3 TLP291-4 Real Image4
Same model may have multiple batches, images only for reference.
TLP291-4 Toshiba Semiconductor and Storage TLP291-4 real image7472 TLP291-4 real image7473 TLP291-4 Real Image1 TLP291-4 Real Image2 TLP291-4 Real Image3 TLP291-4 Real Image4
TLP291-4 Toshiba Semiconductor and Storage TLP291-4 real image7472 TLP291-4 real image7473 TLP291-4 Real Image1 TLP291-4 Real Image2 TLP291-4 Real Image3 TLP291-4 Real Image4
Same model may have multiple batches, images only for reference.

TLP291-4

Part No TLP291-4
Manufacturer Toshiba Semiconductor and Storage
Catalog Optoisolators - Transistor, Photovoltaic Output
Description Optocoupler DC-IN 4-CH Transistor DC-OUT 16-Pin SO / OPTOISOLTR 2.5KV 4CH TRANS 16-SO
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Toshiba Semiconductor and Storage
Packaging Reel - TR
Status Active
Number of Channels 4
Isolation Voltage 2500Vrms
Minimum DC Current Transfer Ratio 50% @ 5mA
Maximum DC Current Transfer Ratio 400% @ 5mA
Switching Turn-On and Turn-Off Time 3μs, 3μs
Rise and Fall Time 2μs, 3μs
Input Type DC
Output Type Transistor
Maximum Output Voltage 80V
Channel Output Current 50mA
Forward Voltage 1.2V
Continuous forward current- Max 50mA
Vce Saturation (Max) 400mV
Temperature Range - Operating -55°C to 110°C
Mounting SMD (SMT)
Case / Package 16-SO
Win Source Part Number 218172-TLP291-4
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name TLP291-4
Introduction Date March 20, 2012
ECCN EAR99
Country of Origin Thailand
Estimated EOL Date 2026
Ultra Librarian 3D Model Ultra Librarian TLP291-4 CAD Model

Description

The Toshiba Semiconductor and Storage TLP291-4 is a high-popularity electronic component that belongs to the Isolators category.

  • Win Source Part Number: 218172-TLP291-4
  • Status: Active
  • Supply and Demand Status: Balanced
  • Case/Package: 16-SO
  • Minimum DC Current Transfer Ratio: 50% @ 5mA
  • Maximum Output Voltage: 80V
  • Channel Output Current: 50mA
