Same model may have multiple batches, images only for reference.
EKZE500ELL561MK25S United Chemi-Con
Same model may have multiple batches, images only for reference.

EKZE500ELL561MK25S

Part No EKZE500ELL561MK25S
Manufacturer United Chemi-Con
Catalog Aluminum Capacitors
Description CAP ALUM 560UF 20% 50V RADIAL / 560 µF 50 V Aluminum Electrolytic Capacitors Radial, Can 5000 Hrs @ 105°C
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Capacitors - Aluminum Electrolytic Capacitors
Mfr Chemi-Con
Series KZE
Package Bulk
Product Status Active
Capacitance 560 µF
Tolerance ±20%
Voltage - Rated 50 V
ESR (Equivalent Series Resistance) -
Lifetime @ Temp. 5000 Hrs @ 105°C
Temperature Range - Operating -40°C ~ 105°C
Polarization Polar
Ratings -
Applications General Purpose
Ripple Current @ Low Frequency 1.205 A @ 120 Hz
Ripple Current @ High Frequency 2.41 A @ 100 kHz
Impedance 23 mOhms
Lead Spacing 0.197" (5.00mm)
Size / Dimension 0.492" Dia (12.50mm)
Height - Seated (Max) 0.984" (25.00mm)
Surface Mount Land Size -
Mounting Type Through Hole
Package / Case Radial, Can
MSL Level Not Applicable
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8532.22.0020
Win Source Part Number 1357972-EKZE500ELL561MK25S
Ultra Librarian 3D Model Ultra Librarian EKZE500ELL561MK25S CAD Model

Description

The 1357972-EKZE500ELL561MK25S is a high-quality aluminum electrolytic capacitor manufactured by Chemi-Con.

  • Series: KZE
  • Application: General-purpose
  • Capacitance: 560 µF
  • Voltage Rating: 50 V
  • Operating Temperatures: -40°C to 105°C
  • Tolerance: ±20%
  • Ripple Current (Low Frequency): 1.205 A @ 120 Hz
  • Ripple Current (High Frequency): 2.41 A @ 100 kHz
  • Package: Radial, Can
  • Mounting Type: Through-Hole
  • Lifetime: 5000 hours @ 105°C
  • Size: 0.492" diameter
  • Height: 0.984"
  • Product Status: Active
  • REACH: Unaffected
