LH1522AACTR Real Image LH1522AACTR Real Image
Same model may have multiple batches, images only for reference.
LH1522AACTR Real Image LH1522AACTR Real Image
LH1522AACTR Real Image LH1522AACTR Real Image
Same model may have multiple batches, images only for reference.

LH1522AACTR

Part No LH1522AACTR
Manufacturer Vishay
Catalog Solid State Relays
Description Dual 1 Form A Solid State Relay
Datasheet
LH1522AACTR Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Relays
Manufacturer Vishay Semiconductor Opto Division
Series LH1522
Packaging Reel - TR
Circuit DPST (2 Form A)
Output Type AC, DC
On-State Resistance (Maximum) 10 Ohm
Load Current 120mA
Voltage - Input 1.26VDC
Voltage - Load 0 ~ 200 V
Mounting SMD
Termination Style Gull Wing
Package 8-SMD (0.300", 7.62mm)
Manufacturer Package 8-SMD
Relay Type Relay
Win Source Part Number 1196393-LH1522AACTR
Manufacturer Homepage www.vishay.com
Popularity Medium
Supply and Demand Status Limited
Family Name LH1522AAC
Introduction Date August 28, 2001
ECCN EAR99
Country of Origin China
Estimated EOL Date 2022
Ultra Librarian 3D Model Ultra Librarian LH1522AACTR CAD Model

Description

The LH1522AACTR is a DPST (2 Form A) relay from Vishay Semiconductor Opto Division.

  • Popularity: This relay has a medium popularity in the market,
  • Status: and the supply and demand status is limited.
  • Features: The LH1522AACTR is an ideal choice for various applications that require a reliable and cost-effective relay solution.
  • Performance: It has a low on-state resistance and a high load current capacity, making it suitable for various industrial and consumer applications.
