SM5A27HE3/2D Real Image SM5A27HE3/2D label picture
Same model may have multiple batches, images only for reference.
SM5A27HE3/2D Real Image SM5A27HE3/2D label picture
SM5A27HE3/2D Real Image SM5A27HE3/2D label picture
Same model may have multiple batches, images only for reference.

SM5A27HE3/2D

Part No SM5A27HE3/2D
Manufacturer Vishay
Catalog TVS - Diodes
Description TVS Diode Single Uni-Dir 22V 3.6KW Automotive 2-Pin(1+Tab) DO-218AB T/R / TVS DIODE 22VWM 40VC DO218AB
Datasheet
SM5A27HE3/2D Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Circuit Protection
Manufacturer Vishay
Packaging Reel - TR
Status Active
Type Zener
Unidirectional Channels 1
STAND-OFF Voltage (Vwm) 22V
Minimum Breakdown Voltage 24V
Max Clamping Voltage 40V
Peak Pulse Current(Ippm) 55A (8/20μs)
Power Dissipation - Pd 3600W (3.6kW)
Applications Automotive
Temperature Range - Operating -55°C to 175°C (TJ)
Mounting SMD (SMT)
Case / Package DO-218AB
Win Source Part Number 028954-SM5A27HE3/2D
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name SM5A27
Introduction Date February 23, 1999
ECCN EAR99
Estimated EOL Date 2027
Ultra Librarian 3D Model Ultra Librarian SM5A27HE3/2D CAD Model

Description

The Vishay SM5A27HE3/2D is a high popularity, balanced supply and demand state Zener Diode.

  • The device is manufactured by Vishay and is available on the official website of Win Source.
  • The component is designed for automotive applications and has a unidirectional channel.
  • It has a peak pulse current of 55A and a power dissipation of 3600W.
  • It is recommended to use this product for circuit protection.
