The SQD50N10-8m9L is an N-Channel 100 V (VDS) MOSFET from Vishay. This power MOSFET is designed for high-efficiency switching applications, providing a good balance between on-resistance and gate charge. Its robust design makes it suitable for a variety of power management and control tasks.

Applications:

• Synchronous Rectification in AC-DC and DC-DC converters
• Power Supplies
• Motor control circuits
• Load Switching
• DC-DC converters in computing
• Battery management systems

Features:

• N-Channel MOSFET
• Low on-resistance (RDS(on)) for reduced power losses
• High avalanche energy rating
• Logic-level gate drive
• Optimized for fast switching speeds
• TrenchFET Power MOSFET technology
• Lead (Pb)-free plating

Benefits:

• Improved efficiency in power conversion stages
• Reduced heat dissipation due to low RDS(on)
• Simplified gate drive requirements
• Enhanced system reliability due to robust design
• Compact design suitable for space-constrained applications

Additional Details:

The SQD50N10-8m9L features a drain-source voltage (VDS) of 100V and a continuous drain current (ID) of up to 50A, depending on the case temperature and mounting. The on-resistance (RDS(on)) is typically 8.9 mΩ at a gate-source voltage (VGS) of 10V. It comes in a PowerPAK SO-8 single package. The MOSFET is designed to minimize switching losses and maximize efficiency in demanding applications.
