Same model may have multiple batches, images only for reference.

SQJ461EP-T1_GE3

Name: SQJ461EP-T1_GE3
Brand: Vishay
SKU: 795330
Availability: InStock
Rating: 4.93 (48 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	SQJ461EP-T1_GE3
Manufacturer	Vishay
Catalog	Transistors - FETs, MOSFETs - RF
Description	MOSFET P-CH 60V 30A / Trans MOSFET P-CH 60V 30A Automotive 5-Pin(4+Tab) PowerPAK SO EP T/R
Datasheet	SQJ461EP-T1_GE3 Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Discrete Semiconductor Products
Manufacturer	Vishay Siliconix
Series	Automotive, AEC-Q101, TrenchFET
Packaging	Reel package
Channel Type Type	P
Technology	MOSFET
Drain Source Voltage	60V
Current - Continuous Drain (Id) @ 25°C	30A (Tc)
Drive Voltage (Max Rds On, Min Rds On)	4.5V, 10V
Vgs(th) (Maximum) @ Id	2.5V @ 250μA
Gate Charge (Qg) (Maximum) @ Vgs	140nC @ 10V
Input Capacitance (Ciss) (Maximum) @ Vds	4710pF @ 30V
Vgs (Maximum)	±20V
Power Dissipation (Maximum)	83W (Tc)
Rds On (Maximum) @ Id, Vgs	16 mOhm @ 14.4A, 10V
Operating Temperature Range	-55°C ~ 175°C (TJ)
Mounting	SMD
Manufacturer Package	PowerPAK SO-8
Package	PowerPAK SO-8
Win Source Part Number	795330-SQJ461EP-T1_GE3
Popularity	Medium
Supply and Demand Status	Balance
Family Name	SQJ461EP
ECCN	EAR99
Country of Origin	China
Halogen Free	Compliant
Estimated EOL Date	2022
Ultra Librarian 3D Model	Ultra Librarian SQJ461EP-T1_GE3 CAD Model

Alternative Products

Description

The Vishay Siliconix MOSFET is a high-performance electronic component.

Family: SQJ461EP
Channel Type: P
Drain Source Voltage: 60V
Maximum Vgs: ±20V
Input Capacitance: 4710pF @ 30V
Gate Charge: 140nC @ 10V
Maximum Power Dissipation: 83W (Tc)
Current Continuous Drain (Id): 30A (Tc) @ 25°C
Maximum Rds On: 16 mOhm @ 14.4A, 10V
Drive Voltage: 4.5V, 10V (Max Rds On, Min Rds On)
Compliance: AEC-Q101
Series: TrenchFET
Package: PowerPAK SO-8
Mounting: SMD
