TSOP36136TT Real Image
Same model may have multiple batches, images only for reference.

TSOP36136TT

Part No TSOP36136TT
Manufacturer Vishay
Catalog Optical Sensors - Photo Detectors - Remote Receiver
Description SENSOR REMOTE REC 36.0KHZ 45M / Remote Receiver Sensor 36.0kHz 45m Surface Mount
Datasheet
TSOP36136TT Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Sensors, Transducers - Optical Sensors - Photo Detectors - Remote Receiver
Mfr Vishay
Package Tape & Reel
Product Status Active
Sensing Distance 45m
B.P.F. Center Frequency 36.0kHz
Voltage - Supply 2.5 V ~ 5.5 V
Current - Supply 350 µA
Orientation Side or Top View
Mounting Type Surface Mount
Temperature Range - Operating -25°C ~ 85°C (TA)
Base Product Number TSOP36136
Standard Package 1,190 pcs
MSL Level 4 (72 Hours)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.49.9500
Win Source Part Number 937777-TSOP36136TT
Ultra Librarian 3D Model Ultra Librarian TSOP36136TT CAD Model

Description

The TSOP36136TT is a remote receiver photo detector from Vishay.

  • Mounting Type: Surface Mount Device
  • Packaging: Tape and Reel
  • Sensing Distance: 45m
  • Supply Voltage Range: 2.5V to 5.5V
  • Current Supply: 350µA
  • B.P.F. Center Frequency: 36.0kHz
  • Product Status: Active
  • Operating Temperature Range: -25°C to 85°C
